Description

• 2/2.3/3/3.17/4/5/6/8/10mm  Metal Cardan Universal Joint Coupling  Please Noted: Package include: Coupling*1+ machine screw*2+wrench*1(Only one wrench is delivered in line with order.) Size description: 1.The following three types, the outer diameter is 8mm, size is 18mm, screw gap diameter is 3mm: 2.3-2.3mm, 2-2.3mm, 2-2mm 2.The following eight types, the outer diameter is 9mm, length is 23mm, screw hole diameter is 3mm: 3-3.17mm, 3.17-3.17mm, 2.3-3mm, 3-3mm,3.175-4mm, 3-4mm, 4-4mm, 2.3-4mm 3.The following 6 types, the outer diameter is 11mm, length is 23mm, screw hole diameter is 4mm: 4-5mm, 3-5mm, 5-5mm, 4-6mm, 5-6mm, 6-6mm 4.The following three types, the outer diameter is 14mm, size is 35mm, screw gap diameter is 4mm: 5-8mm, 6-8mm, 8-8mm 5.The following 2 types, the outer diameter is 16mm, size is 35mm, screw gap diameter is 4mm: 8 to 10mm, 10 to 10mm 6.The following 2 types, the outer diameter is 20mm, length is 52mm, screw gap diameter is 5mm: 10 to 12mm, 12 to 12mm

•
•
•
•
•
