• PowMr Solar Panels 40W 60W 80W 100W 120W 150W 200W Flexible Portable Solar Cell Solar Plate Kit for RV Car Home Solar System Material of Solar Photovoltaic Components: 1) Internal: Monocrystalline silicon solar cells embedded in PET and EVA sheets 2) Surface: Utilizes zero high molecular weight, water-resistant, and corrosion-resistant transparent or frosted PET supplies 3) Backsheet: Employs 0 high molecular weight, water-resistant, and corrosion-resistant white or black PET materials MODEL POW-LTW 40W POW-LTW 60W POW-LTW 80W POW-LTW 100W POW-LTW 120W POW-LTW 150W POW-LTW 200W Maximum Power (Pm) 40Wp 60Wp 80Wp 100Wp 120Wp 150Wp 200Wp Maximum Operating Voltage (Vm) 18 18 18 18 18 18V 18V Maximum Operating Current (Im) 2 3 4 5 6 eight eleven Open-Circuit Voltage (Voc) 21 21 21 21 21 21 21 Short-Circuit Current (Isc) 2 three 4 6 7 9 12 Solar Panel Dimensions 570*410*1 570*605*1 590*790*1 935*590*1 590*1160*1 780*1050*1 780*1340*1 Solar Panel Weight 1 1 2 2 three three four Crystalline Silicon Monocrystalline Silicon Maximum System Voltage 600V Temperature Coefficient of Short-Circuit Current 0+/-0%/℃ Temperature Coefficient of Open-Circuit Voltage -(2+/-0)mv/℃ Temperature Coefficient of Maximum Power -(0+-0)/℃ Temperature Coefficient of Maximum Current +0/℃ Temperature Coefficient of Maximum Voltage -0/℃ Operating Temperature Range -25℃~+60℃ Power Tolerance +/-5% Maximum Pressure the Module Surface Can Withstand 3m/s(20kg/sq) Hail Pressure Test Fall from a peak of one meter Junction Box Type ABS Cell Efficiency 0 Output Power Tolerance +/-5% Standard Test Conditions AM1 100mW/C ㎡ 25’C Warranty 1-year warranty Fill Factor 0 Packaging Carton

•
•
•
•
•
