DESCRIPTION
ACCESSORIES ( Click the images to the links)
END COVER
D-ST4
JUMPERS BRIDGE
FBS 2/3/4/5/10-6
MARKER STRIPS
ZBFM 6
END STOP
E-UK
MARKER CARRIER
B1
MARKER CLIPS
KLM-A
DIN RAIL
NS35-S
FUSE
5X20 mm
Technical Parameters
Type No
Details
Accessories
PT 4-HESILED
500V/6
0²/0²
L56/H64/W6 mm
End cover:
D-ST4
Plug-in bridge:
FBS2-6 , FBS3-6, FBS4-6, FBS5-6, FBS10-6
Insertion bridge:
NONE
Marker strip:
ZBFM 6
Model Number
PT 4-HESILED
Color
Grey, Black, different color can be personalized
Length/Wide/Height (mm)
L56/H64/W6 mm
Connection formulation
Push-in connection
Material
Nylon PA66
Rated Voltage/Current
500V/6
Cross section, solid/soft Cable
0²/0²
Conductor Size
24-10 AWG, 24-12 AWG
Mounting Type
NS 35/7
Standard
IEC 60947-7-1
LOGO
Customized brand are supported
Certification
CE/RoHS/CQC/ISO 9001
