• Dear, in order for you 3-6V, or 110-220V voltage Please touch us Or notice within the order Thanks! Have a reputable day! Notice 1 The default is flat head, if you'd like a high head, please touch customer support 2 When choosing, you could possibly let us know the serial number, which is proven in the picture below, similar to A1, C3 3 It is a customized product and doesn't help return or replace 4 If there is no pattern you want here, you possibly can send me the high-definition sample you want, and we are able to customize it for you Switch type:power switch button Hole diameter:16mm/19mm/22mm Led color:red/orange/green/blue/white Shell color:black/silvery Operation method:Momentary self-reset/Latching self-locking Led Voltage:12V(for 12-24V) Maximum current:4A Waterproof level:IP66 Contact type:1NO1NC Due to handbook measurement, please allow slightly error Note: Connectors have to be bought individually Difference between Momentary self-reset and Latching self-locking: 1/Self-reset: When you press the button, press-key will routinely return(Like a automobile horn swap it-power on, release it-power off) 2 self-locking: When you press the button, press-key will reside in role until you press back then the press-key return(Like a light change it-power on, press it again-power off) Certificate Wiring Instructions 1 does the signal “C”、"NC" and "NO" means? " NC ": Normal Close " NO ": Normal Open " C " : Common 2 lighting and switches have electrodes? The lamp and switch have no electrode, no need to divide the advantageous and damaging poles when wiring Wiring Diagram 1、The button turns the LED light on and off，the circuit is alway open unless press the button 2、LED lighting are continually on，the circuit is alway open except press the button 3、 The button turns the LED light on and off，the circuit is alway close except press the button 4、LED lighting fixtures are continuously on，the circuit is alway close until press the button

•
•
•
•
•
