• Central Processing Unit (CPU) 1. AMD AM4 slot, supports: AMD Ryzen ™ 5000 Series/Ryzen ™ 5000 G-series/Ryzen ™ 4000 G-series and Ryzen ™ 3000 sequence processors chipset 1 B550 Memory 14 DDR4 DIMM slots, capable of supporting up to 128 GB (single slot helps 32 GB capacity) 2Support DDR4 4733 (O.)/4600 (O.)/4400 (O.)/4266 (O.)/4133 (O.)/4000 (O.)/3866 (O.)/3733 (O.)/3600 (O.)/3466 (O.)/3400 (O.)/3200/2933/2667/2400/2133 MHz 3Supports dual channel memory technology four Supports ECC Unbuffered DIMM 1Rx8/2Rx8 memory* *ECC reminiscence (ECC mode) help varies reckoning on CPU 5 Support non ECC Unbuffered DIMM 1Rx8/2Rx8/1Rx16 memory 6 Supports Extreme Memory Profile (XMP) memory Display Function Based on AMD Ryzen ™ 5000 G-series/4000 G-series processors: 1,1 DVI-D interfaces, able to supporting as a lot as 1920x1200@60 Hz resolution *This DVI-D interface would not help the function of transferring to VGA. 21 HDMI interfaces, capable of supporting as a lot as 4096x2160@60 Hz decision *Supports HDMI version 2, HDCP 2, and HDR. Supports most shared display reminiscence as much as sixteen GB Sound Effects 1. Integrating Realtek ® Audio chip 2. Support for High Definition Audio 3. Supports 2/4/5/7 channels *To activate 7 channel audio output, you must input the audio application to alter the default values of "Advanced Device Settings>Playback Device". Please visit the Gigabyte web content for detailed surroundings instructions. Network 1 Integrating Realtek ® GbE network chip (1 Gbps/100 Mbps) Expansion Slot 1 PCI-E x16 slot (PCIEX16) per CPU: 1. AMD Ryzen ™ 5000 sequence and Ryzen ™ 3000 sequence processors support PCI-E 4 x16 operating specifications 2. AMD Ryzen ™ Ryzen ™ 5000 G-series and Ryzen ™ 4000 G-series processors help PCI-E three x16 operating specifications *To maximize the functionality of your graphics card, make sure you install it within the PCIEX16 slot when putting in a graphics card. 1 PCI-E x16 slot (PCIEX4) in holding with chipset: 1. Supports PCI-E 3 and x4 working specs 1 PCI-E x1 slot (PCIEX1) in response to chipset: 1. Supports PCI-E 3 and x1 operating specifications Storage mechanical device interfac 1 M slot (M2A CPU), CPU based, supporting Socket 3, M key; Type 2242/2260/2280/22110 SSDs: 1. AMD Ryzen "5000 series and Ryzen" "3000 series processors assist SATA and PCle four x4/x2 SSDs 2. AMD Ryzen "" Ryzen "5000G-series and Ryzen" 4000 G-series processors assist SATA and PCle three x4/x2 SSDs 1 M slot (M2B SB), chipset based, supporting Socket 3, M key, form 2242/2260/2280 SSDs: 1. Supports SATA and PCle three x2 SSDs 4 SATA3 interfaces in line with chipset: 1. Support RAID 0, RAID 1, and RAID 10 functions USB in keeping with CPU: 1 USB 3 Gen 1 interfaces on rear window IO Based on chipset: 1 USB 3 Gen1 interfaces, which ought to be related from the USB socket contained in the motherboard by manner of a ribbon cable 2 USB 2/1 interfaces (4 on the rear window 1O, 2 to be linked from the USB socket contained within the motherboard through a cable) Internal socket 1 24 PIN motherboard strength sockets 2 8-PIN CPU strength sockets 3 CPU fan sockets 4 substances fan sockets 5 programmable LED lighting with calories sockets 6 RGB LED lighting fixtures with energy sockets 7 Computer fan smooth strip/RGB LED gentle strip energy socket 8 M SSD slots 9 SATA 3 interfaces 10 motherboard jumper sockets eleven entrance audio sockets 12 USB 3 Gen 1 sockets thirteen USB 2/1 sockets 14 safety encryption module (TPM) sockets (2x6 pins, restricted to apply with GC-TPM2) 15 COM sockets sixteen clean CMOS data pins 17 Q-Flash Plus buttons Rear panel formulation connection socket 1 24 PIN motherboard calories sockets 2 8-PIN CPU energy sockets 3 CPU fan sockets four components fan sockets I/O controller 1 iTE ® I/O management chip Hardware Monitoring 1. Voltage detection 2. Temperature detection 3. Fan pace detection 4. Over temperature caution 5. Fan fault warning 6. Intelligent fan control * Whether the intelligent fan management function is supported relies on assorted Computer fan. BIOS 1. 1 256 Mbit flash 2. Using approved AMI UEFI BIOS 3. PnP 1, DMI 2, WfM 2, SM BIOS 2, ACPI 5 Additional gadget program 1. Support APP Center *The packages supported through way of the APP Center might vary depending on the motherboard; The purposes supported through each program can even fluctuate looking on the specifications of the motherboard. @BIOS EasyTune Fast Boot Game Boost ON/OFF Charge RGB Fusion Smart Backup System Information Viewer 2. Support for Q-Flash Plus 3. Support Q-Flash 4. Suppor Xpress Install PCB specs 1 ATX ; 24 x 24

•
