説明

  • 1* Planetary reducer 1* Key 4* Install screws 110PX Reducer Stage Stage 1 Stage 2 Stage three Reduction ratio 3/4/5/6/8/10 12/15/16/18/20/24/25 /30/32/36/40/48/50/60 64/72/80/96/100/120 /144/160/180/200/216 Input (MM) 19 19 19 Output shaft (MM) 19/22 19/22 19/22 Keyway (MM) 6 6 6 Rated load (N) 70 a hundred and forty one hundred sixty Maximum load (N) one hundred a hundred and seventy 180 Full load performance (%) ninety 86 80 Backlash Precision (arcmin) ≦20 ≦30 ≦45 Rated enter speed (RPM) ≦3000 ≦3000 ≦3000 Protection point (IP) sixty five sixty five 65 Noise (dB) ≦60 ≦60 ≦60 Average provider lifestyles (H) ≈20000 ≈20000 ≈20000 Gear materials 20Cr Carbon steel 20Cr Carbon metallic 20Cr Carbon metallic <

  • Description Picture 2 of itemStep-down Reducer 5 To 1 Planetary Gearbox 3:1,10:1,16:1,50:1,100:1 19mm Input for Nema42 Stepper 110mm Servo Brushless Motor
  • Description Picture 3 of itemStep-down Reducer 5 To 1 Planetary Gearbox 3:1,10:1,16:1,50:1,100:1 19mm Input for Nema42 Stepper 110mm Servo Brushless Motor
  • Description Picture 4 of itemStep-down Reducer 5 To 1 Planetary Gearbox 3:1,10:1,16:1,50:1,100:1 19mm Input for Nema42 Stepper 110mm Servo Brushless Motor
  • Description Picture 5 of itemStep-down Reducer 5 To 1 Planetary Gearbox 3:1,10:1,16:1,50:1,100:1 19mm Input for Nema42 Stepper 110mm Servo Brushless Motor
  • Description Picture 6 of itemStep-down Reducer 5 To 1 Planetary Gearbox 3:1,10:1,16:1,50:1,100:1 19mm Input for Nema42 Stepper 110mm Servo Brushless Motor

レビュー

0 people rated this product
No reviews
提供者:Delsey

Step-down Reducer 5 To 1 Planetary Gearbox 3:1,10:1,16:1,50:1,100:1 19mm Input for Nema42 Stepper 110mm Servo Brushless Motor

0.0
30%$ 105.22$ 149.39
消費税込み
カラー: 19 shaft for servo
19 shaft for servo
19 for brushless
22 shaft for servo
22 shaft for stepper
19 shaft for stepper
サイズ:
数量
在庫は残り 200 のみ
