• ANENG 613 Smart Multimeter 4000 Counts Digital AC/DC Curent Voltage Resistor Measurement three in 1 Professional Test Tools Summary: This multifunctional multimeter is designed and produced according to the security standards of the international electrical security traditional IEC-61010 for digital measuring instruments and hand held digital multimeters Meets the necessities of 600V CAT IV, 600V CAT III, and Pollution Level 2 of IEC61010 Before using this instrument, please read the consumer guide carefully and pay attention to the relevant safety work checklist Specification : Function Range Resolution Precision AC current 0mA-10A 0 ±(2% reading + 10) DC current 0mA-10A zero ±(1 percent reading + 8) AC voltage 0mV-600V 1mV-1V ± (1% studying + 8) DC voltage 0V-600V 1mV-1V ±(1% reading + 5) Resistance 0Ω-40MΩ 0Ω-10kΩ ±(1% studying + 10) Capacitor 0nF-40mF 10pF-1μF ±(6% reading+ 20) Hz 40Hz-4MHz 0 ±(1% reading + 10) Diode √ Temperature°C°F √ Buzzer √ Humidity √ Auto power-off 15 min no operation auto power-off Perpetual calendar √ Weight 126g Alarm clock √ Maximum rely 4000 count Data retention √ Material ABS Backlit reveal √ Battery mannequin AAA Battery*2 (Batteries with out shipment) Low energy prompt √ Package Include(Batteries with out shipment) 1 * Multimeter 1 * Manual 1 * Watch pen line 1 * Packing box 1 * Storage bag Usage Precautions: 1 Do not contact the probes directly with your arms to bypass electric surprise and make sure own security throughout testing 2 Before use, inspect the test probes to guarantee there is not any broken insulation or exposed steel 3 Do now not use the present and voltage levels interchangeably to forestall injury to the instrument four It is best to take away the batteries when now not in use for decades to prevent battery corrosion of different internal components of the tool 5 If you don't know the magnitude of the voltage or latest to be measured, birth with the very best vary and then choose the suitable differ in line with the measured cost

•
•
•
•
•
