Description

• How to clear the signals？ Only one step :Press the learning button(on the Receiver) 8 times How to get the signals？ Step 1: Press the training button(on the Receiver) two times Wait for three seconds; Step 2: Press one button at the handheld remote control Wait for 3 seconds Succeed Specification: Transmitter (Remote) : Operating frequency: 433MHz Power by 2 Pcs 3V CR2016 Battery (Battery integrated ) Material: PVC; Button: 2 buttons; Size: 60mm x 30mm; Operating voltage: 3V ; Operating Current: 12mA; Transmitting power: 10mw; Modulation mode: ASK (AM) Encoding type: Learning Transfers distance: 20~50m Controller (Receiver) : Input Power: AC85-240V 60HZ/50HZ Max current: 10 A RF Frequency: 433Mhz Working temperature:-30~+80 RF operating mode: superheterodyne Receive sensitivity: >97dbm Transmitting distance: more than 50 m ( open space) Remote storage:10pcs Support remote type: Learning code 1527code Size: 47*42*22 (mm) Feature: 1 New mini round wireless panel switch(50mm*50mm*15mm) 2 10A power: suitable for many equipment, more secure to apply three Mini body: can be straight installed within the swap backside box, maintenance and set up are extra handy 4 Up to 50 meters remote vary extra obstacles, the shorter the distance, the more serious the sign loss five After turning off the power, switch on the ability again, the gadget fame is off Note: The relay controller is RF Receivers,the wall swap is RF only change itself cannot management lighting fixtures on off needs to work with rf receiver together

•
•
•
•
•
