Description

• Controller Motor style: Brushless Rated voltage: 36v–60v Rated power:750W Current: 35A±1A(750W) Controller Size: 115mm*62mm*40mm Use for: Electrci Tricycle, ebike, e–scooter, e–car, e–golf automobile and so forth How to use self–study: When using the controller and the motor to work for the 1st time, should first use self–study twine Step 1 Connect the motor wire, Hall wire, battery wire, and different function wires Step 2, connect the self–study wire, the motor rotates forward, let it study routinely for 10–20 seconds, disconnect the self–study wire, hook up with other operate wires, complete the self–study, and do not have to use it in the future How to set the P07: 1 If your motor have velocity sensor twine ( some is the white wiring in hall), the P07 set to at least one 2 If your motor without velocity sensor wire ( corridor is 5 wiring) , so you should know your motor magnet quantity and motor tools ratio P07= magnet * tools ratio ( ex: magnet =20 , tools ratio= 1:4 , so P07 set to 20*4=90 Headlight demonstrate (Turn–on the lighting power) Press and hold the "+" button three seconds to turn on/off ; Set up operation(Only need to set P03, P06, P07, P10, P13) ◆ Press "+" and " –" button together 3 seconds to enter the setting interface; ※ Press "M" button to enter atmosphere item;press up and down button to choose parameter; P01:meter backlight; P02:Mileage unit,0:KM;1:MILE; P03:Voltage level, Base operating voltage; P04:Sleep Time, 0: no–sleep, unit: min P05:Assist position,0:3,1:5,mode; P06: Wheel Diameter, unit: inch;Accuracy:0; P07: Number of velocity magnets , fluctuate :1–100; ( Note: here just for set pace display, doen&;t influence the particular speed) P08:Speed Limit, Range:0–50km/h,50: ability Unlimited speed;(When speed huge than atmosphere speed, Turn off the PWM output) P09:Zero or non–zero start,0:zero start; 1:non–zero start; P10:Drive Mode setting: zero : Power Drive, throttle invalid; ( Assist power) 1: Electric throttle Drive mode, Assist invalid; 2: Both help and throttle are effective; P11:Boost sensitivity setting, range:1–24; P12:Boost start energy setting, range:1–5; P13:PAS Assist Type Setting( 5/8/12) Single Hall PAS : set to 5 /8 Double Hall PAS : Set to 12 P14 :P15:Not opened functions; P16:ODO clear; long press up button 5 seconds to clear;

•
•
•
•
•
