Description

• Mean Well LRS-100-3 5V 12V 15V 24V 36V 48V Switching Power Supply meanwell AC/DC 100W unmarried output LRS-100-3 LRS-100-5 LRS-100-12 LRS-100-15 LRS-100-24 LRS-100-36 LRS-100-48 Features Universal AC enter / Full rang Withstand 300VAC surge input for five moment No load strength consumption<0 Miniature size and 1U low profile High working temperature as much as 70°C Protections: Short circuit / Overload / Over voltage Cooling by way of free air convection Compliance to IEC/EN 60335-1(PD3) and IEC/EN61558-1,-2-16 for family appliances Operating altitude up to 5000 meters Withstand 5G vibration verify High efficiency, lengthy lifestyles and high reliability LED indicator for power on Over voltage category III 100% full load burn-in verify three years warranty Description LRS-100 sequence is a 100W single-output enclosed type power delivery with 30mm of low profile design Adopting the complete range 85-264VAC input, the whole sequence presents an output voltage line of 3, 5V, 12V, 15V, 24V, 36V and 48V Applications Industrial automation equipment Industrial control formulation Mechanical and electrical kit Electronic instruments, equipments or equipment Household home equipment

•
•
•
•

Review
