Description

• MINCO HEAT 10 to one hundred Meters 12K Floor Warm Heating Cable 33ohm/m Carbon Fiber Heating Wires Product Details: Product Name: Carbon fiber heating wire Insulating materials: Silicone rubber Temperature: 2 hundred levels celsius restrict Heating conductor: 12K High voltage test: 3000V Leakage current: 0/m The product can withstand the power of power: 25W/M Diameter: 3±0 MM Optional colors: Red and Yellow, please leave a message for the specified color Infrared wavelength: 8UM-18UM Conductor resistance: 33±10%Ω / M Length: (custom, no longer less than 10 meters) Package Includes: Buy 100m = 100m cable + 20 pcs copper tube + 20 pcs sleeves Buy 50m = 50m cable + 10 pcs copper tube + 10 pcs sleeves Buy 30m = 30m cable + 6 pcs copper tube + 6 pcs sleeves Buy 20m = 20m cable + 4 pcs copper tube + 4 pcs sleeves Buy 15m = 15m cable + 4 pcs copper tube + 4 pcs sleeves Buy 10 m = 10m cable + 2 pcs copper tube + 2 pcs sleeves How to calculate power? Voltage*Voltage÷resistance=electric strength 12K=33ohm/meter For example, utilizing 10m 12K carbon fiber cable on 220V, the ability is: 220V*220V÷(10meters*33Ω)=150W For example, using 15m 12K carbon fiber cable on 220V, the power is: 220V*220V÷(15meters*33Ω)=100W The longer length, the smaller power, and decrease heating temperature What is the ability of the cable? And what's heating temperature? 1 The energy of the cable relies at the size that you use, you possibly can calculate the ability in line with above examples 2 Power = 5W/m, the temperature is set 30~40C degrees; Power = 10W/m, the temperature is set 40~50C degrees; Power = 15W/m, the temperature is about 50~60C degrees; Power = 20W/m, the temperature is about 60~70C degrees; Power = 25W/m, the temperatuee is set 70~90C degrees Please word that here's for your reference, now not precisely right due to assorted verify situations Product Photos: How to wiring? Product Applications: 1 Floor heating for Home and office: Homes, villas, hotels, workplace buildings, hospitals, shopping malls 2 Floor heating for public areas: Swimming pool, football field, gymnasium, museum, memorial hall, the kindergarten three Floor heating for large public facilities: Bus terminal, parking lot, airport, highways four Floor heating for pro field: Botanical garden, greenhouse, laboratory And different heating purposes Product Advantages: 1 energy-efficient: Don&;t want different transmission medium, the electrothermal conversion performance is above 98% 2 and healthy: New infrared floor heating, make the temperature uniformity, promote blood move three to install: The carbon fiber heating wire cost a little, and has a long life span, an investment, life-long benefit, low upkeep fees And and many others

•
•
•
•
•
