Description

• ABOUT THERMOSTATS The BHT-009 vary has been evolved to control electric underfloor ,water heating or water/gas boiler components These units are designed to be used in commercial, industrial, civil and domestic properties GA： for water heating; GB： for electrical heating; GC：for fuel boiler; Thermostat 1pc Screws 2pc User Guide 1pc QC Passed 1pc Floor Sensor 1pc (Floor Sensor is Optional) TECHNICAL DATA Current Load: 5A (water heating, waterlgas boiler), 16A (electric heating) Sensor: NTC3950, 10K Network: ZigBee / Wi-Fi App: Smart life/Tuya Accuracy: ±1°C Set Temp Range: 5-35°C Room Temp Range: 5-70°C Display Temp Range: five ~ 70°C Ambient Temp: 0~ 45°C Ambient Humidity: 5 ~ 95 % RH (Non Condensing) Storage Temp:-5~ 45°C Power Consumption: <1 5W Timing Error: < 1% Shell Material: PC +ABS ( Fireproof) Installation Box: 86 * 86mm Square or European 60mm Round Box Wire Terminals: Wire 2 x 1 mm2 or 1 x 2 mm2 Buttons: Capacitive Touch Buttons

•
•
•
•
•
