Preces apraksts

• Dmx LED Lights Strip Controller 512,Dmx Signal Distributor LED Amplifier Splitter DMX121 DMX512 Signal Repeater for DMX Controllers DMX121 sign distributor is one in every of DMX sign distributor series, is specifically used for amplifying DMX512 digital light fixtures control signal. The input/output interface adopts excessive voltage isolation technology, utilized to develop DMX512 signal transmission in the brief distance, as well as the using event where output/input interfaces needs to be total electrical isolation. Due to the independent isolation between input/output interface, it'll avoid burning precision digital light console through the problem of the controlling circuit, decoder, laptop light, silicon field and so on, to guarantee the secure operation of electronic lights control, and in addition make certain DMX sign can common move to all types of light fixtures equipment, to be able to improve reliability for the complete digital lighting fixtures management system. Technical parameters: 1●Working temperature : -20-60℃ 2● Input voltage : AC one hundred ~ 240V 50～60HZ 3● Rated energy : 2W 4● Input signal : 1 channel DMX512 signal 5● Output sign : 1 channel DMX512 signal output, the output port would be related to 32 equipments mostly. 6● The isolation voltage between input/output interface : > 1000V 7● Cascade quantity : can cascade 16pcs signal amplifier mostly. 8● Net weight : 361g 9● Gross weight : 620g 10● External dimension : L146*W71*H39mm 11● Packing length : L185*W150*H65mm External Dimension Interface Specification 1,AC100～240V energy interface 2,DMX signal kalong enter interface 3,DMX signal kalong output interface DMX XLR interface Power interface:Access to AC100-240V Signal comfortable specification 1. Power light: light is on - Power on; Light is off - strength off 2. DMX512 IN light: gentle is on - DMX512 sign input normal; Light is off - DMX512 signal without input or unnormal 3. DMX512 OUT1～DMX512 OUT4 light: delicate is on - DMX512 signal output normal; Light is off - DMX512 sign output failure Product assembly structure and packing plan Product and equipment description: 1 DMX121 sign distributor 1PCS 2 PE Foam 2PCS three XLR Male 9PCS 4 XLR Female 1PCS 5 Specification 1 PCS 6 AC Power cable 1 PCS 7 outer-package 1PCS Direction for Use According to the panel of DMX amplifier, to attach enter and output sign wires to be able to make sure quick circuit cannot happen between wires, after which connect strength to DMX amplifier, it is going hand in hand with DMX decoder, please seek advice from the ensuing common applications. Typical utility Package included: 1 piece * DMX121 1 Channel DMX Distributor Dmx controller,Bluetooth controller,rgb controller,zigbee,LED lights controller,controllers,dmx,controllers,controls,led lighting fixtures controller,dmx mild controller,argb controller,led dimmer 12v,led controller, dimmer,dimmer wifi,led dimmer,dimmer led,controllers,Chanel,wifi led controller,midi controller, artnet dmx,wireless dmx,dmx decoder,WiFi LED tape controller,dmx splitter,control units,wireless dmx,Wireless controller,dmx512,single led controller,rgb led exchange fi wi, led tape controller,led controller,controls for led lights,tuya driver led,led strip controller,dmx controller 512,control dmx,

•
•
•
•
•
