• L298N： Module name: dual H bridge motor pressure module Work mode: H bridge power (double road) Main management chip: L298N Packaging: electrostatic bag Logical voltage: 5V Drive voltage: 5v-35v Logical current: 0mA-36mA Driving current: 2A(MAX single bridge) Storage temperature: - 20 ℃ to + a hundred thirty five ℃ Maximum power: 25W Peripheral dimensions:43*43*27mm Product features: This module USES L298N because the main drive chip, with solid driving ability, low heat and strong anti-interference ability Through this module can use the integrated 78 m05 power energy delivery parts in their work, but as a way to keep away from the voltage regulator chip damage, when using the driving voltage is greater than 12 v, please use the external power delivery five v good judgment This module USES a large capability filter out capacitance, a continuation defense diode, can upgrade reliability Notes: 1 When you are driving voltage (above brand for the 12 v input, can truthfully accept input vary is 7 to 12 v) for 7 v to twelve v, could make to onboard energy delivery five v logic, when using the onboard after five v energy supply, interface of + 5 v The energy supply would not input voltage, yet can yield 5V voltage for exterior use 2 When the driving voltage is higher than 12V, it is less than or equal to 24V (the chip handbook proposes to assist 35V, but per the book When the utmost voltage is applied to the utmost voltage of 298 conservative purposes to 24V, for example, the motor with a rated voltage of 18V will probably be driven You must first eradicate the board 5V output to enable the jumper cap Then 5V is accessed exterior the 5V output port The 5V permits the flexibility to be a control sign with a degree of 5V When the signal enter is valid, and when the ability delivery is ordinary in the motor pressure module, the motor pressure module outputs the current Otherwise, even if the ability delivery is normal, there's no recent at the motor Voltage to L298N inner good judgment circuit power delivery (this is a high-pressure, unconventional app!) Mini-L298N： motor power module is awfully compatible for use in battery powered smart car, toy car, robot and so on, the supply voltage of 2V~10V can concurrently power two DC motor or 1 four line 2 part stepper motor, can obtain nice and speed control function, each recent to at least one continuous current The peak latest is up to 2,with thermal defense and automated restoration Product highlights: 1 imported legit motor driving force chip, built-in low conduction resistance swap MOS, heating minimum,without radiator, small volume, calories saving, is your ideal preference for battery powered(L298N internal transistor switch, low efficiency, high fever, without heat, heavy volume, the market of L298N is easy to burn out, don't use the unique chips, this product would be the best replacement) 2 twin 1*2, height latest to 2, built-in overheat defense circuit, don't be petrified of motor stalling burn,automatic restoration after falling temperature (the wise car voltage and recent for sale are within this range) 3 small size, mild weight, 0 standby current, is your preferrred desire for car mannequin Product parameters: H bridge motor dual drive, and can drive two DC motor or 1 line four phase stepper motor; The voltage of the power supply module 2V-10V; The signal input voltage 1; Single channel latest of 1, peak latest as much as 2, low standby current (less than 0); The built-in ordinary conduction circuit, the enter end is suspended, the motor will not malfunction; The built-in overheat defense circuit with hysteresis impact (TSD), there's no deserve to worry about motor stall; Product size: 24*21*5mm (LxWxH), ultra small size, appropriate for meeting and vehicle; Mounting gap diameter: 2 mm Package contains:1PCS ×Mini victory L298N

•
•
•
•
•
