CE/EMC Certified, High Efficiency Full Power 7000W Peak Power 3500W Single Phase Off Grid Pure Sine Wave Solar Power Inverters Converters DC TO AC Voltage Transformer LED Display Iron Shell
About us:
-Our corporation is the leading and professional producer for 150w to 8000w DC TO AC OFF GRID PURE SINE WAVE INVERTER Our legitimate technical department, will help the finest technical service and after-sale technical provider
-Our precept is “quality first, customer priority, provider best, commerce honest”
-With the excessive quality, favorable fame, excellent service, our strength inverters are offered world wide We have many loyal visitor in the Europe, America, Asia, and so on
-All inverters are stricktly inspected earlier than leaving factory, Reliable Company Guarantees that each inverter is in its ideal working condition
About avantage of our inverter:
1 quality transformer
As the core components, move the DC power to AC power, we use the excessive frequency transformer, ensure the steady and full AC output, no failure
2 capacitor
Adapted the imported capacitor, wide electricity, higher performance, longer lifetime, more secure utilization
three copper inductance
High high quality true copper inductance, clear out the wave form, ensure the true pure sine wave AC output, safeguard your package
4 tested
No electromagnetic interference to your equipment, similar to no noise for TV, FM radio, Audio
5 flange
With the massive radiating flange, higher cooling performance, ensure the excellent inverter working situation
6 mosfet
All huge mosfet, bigger load capacity, stable the inverter performance, supply the continuous AC output
7 line connection
Earthe connection for either PCB board and output, extra secure for the load and the utilization
eight thickness
The PCB thickness of 2, thicker than probably the most inverters on the market, enable the stronger current floating at the circuit, develop the burden means
Applications of Our Customers:
Product Detail Parameters
DC Voltage
12V or 24V or 36V or 48V or 60V or 72V or 96V or 110V
Voltage Range
10-15VDC or 21-30VDC or 30V-45VDC or 42-55VDC or 55V-75VDC or 60V-90VDC or 85V-120VDC or 100-130VDC
NO Load Current Draw
<1A
Efficiency
>90%
DC Connector
Cables With Clips or Car Adaptor
AC Voltage
100/110/120VAC or 220/230/240VAC
Continuous Power
3500W
Surge Power
7000W
Waveform
Pure Sine Wave
Frequency
50HZ or 60HZ
AC Regulation
3%
Low Voltage Alarm
10DC±0 or 20±1V or 32±1V or 44±1V or 55±1V or 68VDC±1V or 92VDC±1V or 105VDC±1V
Low Voltage Shut Down
9±0 or 19±1V or 31VDC±1V or 42VDC±1V or 55VDC±1V or 60VDC±1V or 84VDC±1V or 100VDC±1V
Over Load
Shut Off Output
Over Voltage Shut Down
15 or 30 or forty five or 55 or seventy five or 90 or a hundred and ten or 120
Over Thermal
Shut Off Output Automatically
Fuses
Short Circuit
Working Temperature
Between -10centi and +50centi
Working Humidity
20%~90%RH non-condensing
Storage Temperature
Between -30centi and +70centi
Start
Soft Start
Cooling Ways
Cooling Fan
Total Harmonic Distortion THD
<5%
Machine Size(mm)
550*240*95
Packing Size(mm)
630*330*210
Net Weight(kgs)
8KG
Gross Weight(kgs)
nine
Packing Type
Carton Packing
Feartures:
Pure Sine Wave, pretty much as good because the grid strength
Full Power
Core Technology, German Design
Most Advanced Program in Software
Complete Protection Non Defect Rate,
Better EMC - Electro Magnetic Compatibility,
No Noise for TV or Stereo Sound
SMT- Surface Mounting Technology
All Big Imported Mosfet,Strong Driving Capacity
PCB Thickness :2
LED Display
Compact Design, Less Weight, Full Power,
Single Layer Design, Easy to Repair if any
Earth Connection for Both Inverter and PCB,
Low No Load Current Draw
Durable quality with 10 years usage,
Alarm and LED Indication Light for error warning inevrter with LED display, allow you to video display the inverter enter voltage and output voltage in time With this function, you will know about the inverter situation more obviously
Sufficient Heat Radiation
More Vent Holes at the plates and the bottom for warmth radiation
Popular Metal Black Design
Big Current Connector,
All forms of socket are available
Strong Wiring Row on AC End,
Best high quality ever in the market
Factory Price
Product Details:
Protection Systems:
Thermal protection, Overload protection, Over Voltage protection, Under Voltage protection, Low Voltage protection alarm Inverter comes with an LED gentle to indicate the difficulty
9 sorts of protections:
1 circuit production
When the burden is brief circuit, the inverter will stop working
2 High temperature production
When the use environment is stuffy, the warmth of the inverter can't be radiated The temperature is above the rated temperature, the inverter will quit working
3 High voltage protections
The battery voltage is above the rated voltage of the inverter, the inverter will quit working
four Low voltage protections
The battery’s voltage falls in the course of the usage When it is less than the rated voltage, the inverter will automatically minimize the input voltage for the self defense
5 Surge protection
It can avoid the DC excessive voltage’s surging attack upon the digital ingredients within
6 Overload defense
When the appliances’ strength is increased than the inverter’s power, the inverter will stop operating for self protection
7 Over latest Protection
When the appliances’ current is larger than the inverter’ current, the safety ingredients at the board might be minimize routinely for self defense
8 defense
When the appliance’s resistance is bigger than inverter’s, the fuses at the socket may be automatically bring to an end for self protection
9 Reverse protection
It can keep away from the accidents of burning the inverter if the tremendous and the negative poles are reverse related
The Resistive Load Applications and The Inductive Load Applications:
For resistive load applications:
If you need the inverter to run the resistive load (like laptop, TV, electrical cooker, LED light), please choose the inverter with continuous power larger than the appliance&;s rated power
For example, for the power inverter with continual energy 2500w,it is advised to run the application with rated power lower than 2500w It is best to apply 80% of the rated power
For inductive load applications:
If you would like the inverter to run the inductive load (for appliance corresponding to compressor, motor, water pump), please calculate the power of inverter 3 to 7 instances increased than the rated strength of your appliance
Product Certification:
Durable and secure high quality with decades usage, our natural sine wave inverters are accredited through EMC trying out in Australia and CE licensed 18 months guarantee
Product Packaging:
The Transportation:
For the small capacity, The inverter may be sent through DHL, EMS, FedEx and e-EMS, it'll take 3-12 days for shipping
If you would like wide quantity, please contact with me concerning the delivery process
Customer Service:
1 RELIABLE is your depended on companion for future enterprise are the MANUFACTURER of the solar inverter We are accountable for the standard of the inverter The inverter has ONE year guarantee We provide technical assist and repair for the inverter the entire lifestyles
All inverters can be double examined earlier than cargo to be guaranteed in fresh situation and work perfectly
2 Returns for substitute are approved and ought to be initiated via the buyer inside 4 days of receipt All go back items ought to be in their original situation Return transport and handling price may be at the buyer&;s expense first Please do touch with us for return address, particulars and every other issues
3 We aren't accountable for any put off throughout shipping including but now not limited to the customs equipment checking, strike, force majeure, and so forth
4 In case there's subject along with your order, ensure CONTACT US before leaving negative feedback Leaving adverse feedback with out communication is a contravention of feedback policy
5 Please leave us message if in case you have any question, we can reply in 24 hours, thank you
How to choose a correct inverter:
We accept the custom-made made inverter for each customer, please go away me a messages of your inverter specifications:
Leave me these kind of specifications by means of sending me a message, so that I could make sure of a fast shipping!
Our inverter is unmarried phase inverter, there may be only 1 input voltage and output voltage for each inverter, the output voltage cannot be splitted into smaller voltage Such because the 240V can't be splitted into 120V
1&;s your input voltage?12v or 24v or 36v or 48v or 72v or 110v?
(attention please: only one voltage would be choose! If the input is 48v or 72v, the extra 10% price can be needed, if the input is 110v, the extra 15% charge may be mandatory If you need remote controller, we need more 15 USD Please contact with me I&;ll change your price, or you pays us through paypal)2&;s your output voltage? 100v or 110v or 120v or 220v or 230v or 240v?
3&;s your frequency? 50HZ or 60HZ?
4&;s your socket type? please examine the image I connected and make a decision
