• 3PCS one hundred Degree Camera Module 1MP OV9732 1280x720 USB Free Driver Manual Focus, with 2 Meter Cable for WinXP/7/8/10 1 Photosensitive film: (1/4inch ) 2 The best possible effective pixel: 1280(H)x720(M) three Lens Size: 1/4 inch (4: 3) four Pixel Size: 3 five Image area: 5 x four 6 Output image format: MPEG/YUV2 (YUYV) 7 Supported resolutions and frame rates: 1280x720@30fps MJPEG 1280x720 @10fps Yuv 800x600 @30fps MJPEG 800x600 @15fps Yuv 640x480 @30fps MJPEG 640x480 @30fps Yuv 8 Camera board meeting technology: SMT nine Focus: Fixed 10 Center definition: 600LW/PH (Center) 11 Signal-to-noise ratio: TBD 12 Dynamic range: TBD thirteen Sensitivity: 1/lux-sec@550nm 14 Minimum illumination: 0 15 Shutter type: Electronic rolling shutter / Frame exposure sixteen Interface type: USB 2 High Speed 17 Automatic publicity management AEC: supported 18 Automatic white balance AEB: supported 19 Automatic achieve control AGC: supported 20 Adjustable parameters: brightness/contrast/color saturation/hue clarity/gamma/white balance/backlight contrast/exposure 21 specifications: Size: 1/4 Focal length: 2 Aperture F2 diagonal:77° Interface M12xP0 Colour:Black Material:plastic+metal Package Contents: 3 x one hundred Degrees OV9732 Camera Module 3 x 2m USB Cable Only the above package content, other merchandise aren't included Note: Light reflection and different displays could cause the colour of the thing within the photo just a little various from the real factor The measurement allowed error is +/- 1-3cm

•
•
•
•
•
