• Specification parameters: Mainframe size: 69mm lengthy * 30mm huge * excessive 30mm. Circuit size: forty seven lengthy * 31 large * excessive 16mm. Output wavelength: 520 nm. Output power: 100mW 120mW 150mW 1W optional. Cooling mode: aluminum heat dissipation. Modulation frequency: modulable. Working characteristics: can paintings continuously. Surface treatment: blue / green. Shell material: aviation aluminum. Circuit control: step-down constant current. Reverse protection: with automatic identification of wonderful and detrimental poles. Operating voltage: DC=12V. Working current: 100mW < I < 1. Warm-up time: none. Working temperature:-10 ℃ ~ + forty ℃. Storage temperature:-10 ℃ ~ + 40 ℃. Structural features: laser tube + lens + warmth dissipation shell. Note: the power shipping is external. 1W绿光采用40*40mm散热件(其它同100-200mW的图片)，以提高产品的稳定性. package:1pcs 520/525nm Green Laser Module

•
•
•
