• Note: Different product items have varied appearance, length and weight parameters. We have quite a lot of harmonic reducers and in addition support customized harmonic reducers. You can touch customer service team to obtain 3-D renderings and design size drawings.   Reduction ratio: 50 Rated torque when inputting 2000r/min: 76 Nm Allowable top torque when beginning and stopping: 216 Nm Allowable most price of common load torque: 108 Nm Instantaneous most allowable torque: 382 Nm Allowable maximum input speed: 4800 Allowable common input speed: 3500 Moment of inertia: 1.69 Backlash: 10AS Weight: 3.1KG         Reduction ratio: eighty Rated torque when inputting 2000r/min: 118 Nm Allowable peak torque when beginning and stopping: 304 Nm Allowable most value of common load torque: 167 Nm Instantaneous maximum allowable torque: 568 Nm Allowable maximum enter speed: 4800 Allowable average enter speed: 3500 Moment of inertia: 1.69 Backlash: 10AS Weight: 3.1KG         Reduction ratio: a hundred Rated torque when inputting 2000r/min: 137 Nm Allowable height torque when starting and stopping: 333 Nm Allowable maximum cost of average load torque: 216 Nm Instantaneous maximum allowable torque: 647 Nm Allowable most input speed: 4800 Allowable average input speed: 3500 Moment of inertia: 1.69 Backlash: 10AS Weight: 3.1KG

•
•
•
•
•
