• NOTE: the colour of head might various for different batches If you care about the color, pls depart note Model M3 M4 M4 screw M5 screw M6 screw NPN 3wire NO LJ3A2-1-N1 LJ4A2-1-N1 LJ4A3-1-N1 LJ5A3-1-N1 LJ6A3-1-N1 NPN 3wire NC LJ3A2-1-N2 LJ4A2-1-N2 LJ4A3-1-N2 LJ5A3-1-N2 LJ6A3-1-N2 PNP 3wire NO LJ3A2-1-P1 LJ4A2-1-P1 LJ4A3-1-P1 LJ5A3-1-P1 LJ6A3-1-P1 PNP 3wire NC LJ3A2-1-P2 LJ4A2-1-P2 LJ4A3-1-P2 LJ5A3-1-P2 LJ6A3-1-P2 DC 2wire NO - - - LJ5A3-1-D1 LJ6A3-1-D1 DC 2wire NC - - - LJ5A3-1-D2 LJ6A3-1-D2 AC 2wire NO - - - - LJ6A3-1-A1 AC 2wire NC - - - - LJ6A3-1-A3 Principle switching transducer Frequency 500Hz Shape cylind M3/M4/M5/M6 Load recent 300mA Working voltage 10-30VDC; 110-220vAC Protection Ingress IP65 Sensing distance 0, 1mm Operating Temperature -25 to +70℃ Mounting flush Indicator Red LED

•
•
•
•
•
