• PowMr MPPT 80A Solar Charger 3000W Inverter DC 24V Wide Voltage LCD Display Hybrid Solar Inverter 220V AC Solar Panel PV 450Vdc Note: 3000W The PV input voltage differ is 90~430V, and the minimum PV input voltage is 120V Introduction This is a multi-function inverter/charger, combining applications of inverter, solar charger, and battery charger to supply uninterruptible energy help with transportable length Its comprehensive LCD reveal presents user-configurable and easy-accessible button operation resembling battery charging current, AC/solar charger priority, and applicable enter voltage in accordance with varied applications Product Features 3000W+MPPT 80A+24V Hybrid Inverter Pure sine wave inverter ●Configurable input voltage vary for home home equipment and private computer systems through LCD setting ●Configurable battery charging recent based on purposes through LCD environment ●Configurable AC/Solar Charger precedence via LCD setting ●Compatible with mains voltage or generator strength ●Auto restart while AC is getting better ●Overload/ Over temperature/ quick circuit defense ●Smart battery charger design for optimized battery performance ●Cold birth function ●WIFI/GPRS(Option) ●Can connect with lithium battery Basic System Architecture The following representation shows the fundamental utility for this inverter/charger It also includes the following instruments to have a complete running system: • Generator or Utility • PV modules Consult together with your formula integrator for other probable system architectures looking on your standards This inverter can energy all kinds of appliances in-home or office environment, adding motor-type appliances such as tube lights, fans, refrigerators, and air conditioners All-Round Protections The PowMr inverter charger gives 4 charging stages, safeguards opposed to overload, over-temperature, and brief circuits, and lines automated restart It involves clever fans that boost battery performance, minimize heat, and increase formulation longevity A cold start function also is accessible MPPT Charge Controller Compatible with Various Batteries Versatile Working Modes Customize the priority of energy inputs and outputs with four charging modes(Only Solar, Mains First, Solar First, Mains&Solar) and a pair of output modes(Solar First, Utility First) This inverter charger affords effective energy leadership for custom-made calories intake Product Specification INVERTER MODEL 1600W-12V 3000W-24V Input Voltage Waveform Sinusoidal(utility or generator) Nominal Input Voltage 230Vac Low Loss Voltage 170Vac士/7V（UPS）； 90Vac±7V（Appliances） Low Loss Return Voltage 180Vac±7V(UPS); 100Vac±7V(Appliances) High Loss Voltage 280Vac±7V High Loss Return Voltage 270Vac±7V Max AC Input Voltage 300Vac Nominal Input Frequency 50Hz/60Hz(Auto detection) Output Short Circuit Protection Circuit Breaker Efficiency(Line Mode) >95%(Rated R load,battery full charged) Transfer Time 10ms typical(UPS); 20ms typical(Appliances) Inverter Mode Specifications INVERTER MODEL 1600W-12V 3000W-24V Rated Output Power 2000VA/1600W3200VA/3000W Output Voltage Waveform Pure Sine Wave Output Voltage Regulation 230Vac±5% Output Frequency 50Hz Surge Capacity 2*rated power for 5 seconds Nominal DC Input Voltage 12Vdc 24Vdc No Load Power Consumption <25W <35W Charge Mode Specifications Charging Algorithm 3-Step AC Charging Current(Max) 60Amp Floating Charging Voltage thirteen 27Vdc MPPT Solar Charging Mode Max Array Power 2000W 3000W Nominal PV Voltage |240Vdc PV Array MPPT Voltage Range 30~400Vdc Max Array Open Circuit Voltage 400Vdc Max Charging Current (ac charser pus photo voltaic charger) 80Amp General Specifications Safety Certification CE Operating Temperature Range -10℃ to 50℃ Storage Temperature -15℃- 60℃ Product Pictures

•
•
•
•
•
