• DC Motor Reverse Polarity Switch Module DC 5V 6V 9V 12V Time Adjustable Delay Relay 2A Drive Current Signal Generator Board Features: 1 advantageous materials with guaranteed high quality 2 functionality and large voltage range 3 to use and easy to understand wiring four and compact appearance five software range, appropriate for various commercial events Parameters: Working voltage: DC 5-13V Working current: 5V ahead rotation: 4mm; Reverse: 36ma 12V ahead rotation: 6ma; Reverse: 44ma Load voltage: DC1-48V or AC 85-265V Load current: maximum 2A Maximum ahead rotation time: 5000 seconds (up to 40000 seconds could be carried out by means of shorting the solder pad), in steps of 0 seconds Maximum opposite time: 5000 seconds (up to 40000 seconds would be executed via shorting the solder pad), in steps of zero seconds Usage: VIN is connected to the high-quality pole of the operating power supply, and GND is attached to the unfavorable pole of the operating power supply; P+is connected to the tremendous pole of the motor power supply, and P - is hooked up to the damaging pole of the motor energy delivery M+is connected to motor input terminal 1 (the motor would not distinguish between high quality and unfavourable poles), and M - is attached to motor input terminal 2 After powering on, D1 flashes for 3 instances and then goes out, D2 is going out, M+outputs positive, M - outputs negative, and the motor rotates forward; After a delay of T1 time, D2 lighting fixtures up, M+outputs negative, M - outputs positive, and the motor reverses; After delaying T2 time, D2 is going out, M+outputs positive, M - outputs negative, the motor rotates forward, and so on T1: represents the forward rotation postpone time, which is adjustable via default from 0 to 5000 seconds (in steps of zero seconds) A delay of 1-8 instances would be set during the pad (up to 40000 seconds) T2: Refers to the opposite put off time, which is adjustable via default from zero to 5000 seconds (in steps of zero seconds) A put off of 1-8 occasions would be set in the course of the pad (up to 40000 seconds) Package include: Delay module * 1

•
•
•
•
•
