CE/EMC Certified, High Efficiency Full Power 12000W Peak Power 6000W Single Phase Off Grid Pure Sine Wave Solar Power Inverters Converters DC TO AC Voltage Transformer LED Display Iron Shell
About us:
-Our corporation is the main and professional manufacturer for 150w to 8000w DC TO AC OFF GRID PURE SINE WAVE INVERTER Our legitimate technical department, will support the best technical provider and after-sale technical service
-Our precept is “quality first, visitor priority, provider best, commerce honest”
-With the excessive quality, favorable fame, preferrred service, our strength inverters are sold around the globe We have many dependable visitor within the Europe, America, Asia, etc
-All inverters are stricktly inspected before leaving factory, Reliable Company Guarantees that every inverter is in its best operating situation
About avantage of our inverter:
1 high quality transformer
As the core components, transfer the DC power to AC power, we use the excessive frequency transformer, ensure the secure and full AC output, no failure
2 capacitor
Adapted the imported capacitor, extensive electricity, better performance, longer lifetime, more secure usage
3 copper inductance
High quality true copper inductance, filter the wave form, make sure the true pure sine wave AC output, safeguard your kit
four examined
No electromagnetic interference for your equipment, resembling no noise for TV, FM radio, Audio
five flange
With the big radiating flange, greater cooling performance, make sure the superb inverter working condition
6 mosfet
All massive mosfet, bigger load capacity, stable the inverter performance, supply the continuous AC output
7 line connection
Earthe connection for both PCB board and output, more secure for the burden and the utilization
eight thickness
The PCB thickness of 2, thicker than essentially the most inverters on the market, allow the more potent current floating on the circuit, develop the weight capability
Applications of Our Customers:
Product Detail Parameters
DC Voltage
12V or 24V or 36V or 48V or 60V or 72V or 96V or 110V
Voltage Range
10-15VDC or 21-30VDC or 30V-45VDC or 42-55VDC or 55V-75VDC or 60V-90VDC or 85V-120VDC or 100-130VDC
NO Load Current Draw
<1A
Efficiency
>90%
DC Connector
Cables With Clips or Car Adaptor
AC Voltage
100/110/120VAC or 220/230/240VAC
Continuous Power
6000W
Surge Power
12000W
Waveform
Pure Sine Wave
Frequency
50HZ or 60HZ
AC Regulation
3%
Low Voltage Alarm
10DC±0 or 20±1V or 32±1V or 44±1V or 55±1V or 68VDC±1V or 92VDC±1V or 105VDC±1V
Low Voltage Shut Down
9±0 or 19±1V or 31VDC±1V or 42VDC±1V or 55VDC±1V or 60VDC±1V or 84VDC±1V or 100VDC±1V
Over Load
Shut Off Output
Over Voltage Shut Down
15 or 30 or forty five or fifty five or 75 or ninety or a hundred and ten or one hundred twenty
Over Thermal
Shut Off Output Automatically
Fuses
Short Circuit
Working Temperature
Between -10centi and +50centi
Working Humidity
20%~90%RH non-condensing
Storage Temperature
Between -30centi and +70centi
Start
Soft Start
Cooling Ways
Cooling Fan
Total Harmonic Distortion THD
<5%
Machine Size(mm)
550*380*135
Packing Size(mm)
620*390*260
Net Weight(kgs)
14KG
Gross Weight(kgs)
16KG
Packing Type
Carton Packing
Feartures:
Pure Sine Wave, nearly as good because the grid power
Full Power
Core Technology, German Design
Most Advanced Program in Software
Complete Protection Non Defect Rate,
Better EMC - Electro Magnetic Compatibility,
No Noise for TV or Stereo Sound
SMT- Surface Mounting Technology
All Big Imported Mosfet,Strong Driving Capacity
PCB Thickness :2
LED Display
Compact Design, Less Weight, Full Power,
Single Layer Design, Easy to Repair if any
Earth Connection for Both Inverter and PCB,
Low No Load Current Draw
Durable high quality with 10 years usage,
Alarm and LED Indication Light for error warning inevrter with LED display, allow you to video display the inverter input voltage and output voltage in time With this function, you will know about the inverter situation more clearly
Sufficient Heat Radiation
More Vent Holes at the plates and the lowest for heat radiation
Popular Metal Black Design
Big Current Connector,
All varieties of socket are available in
Strong Wiring Row on AC End,
Best high quality ever available in the market
Factory Price
Product Details:
Attention please: there are 4 DC connections for 12V inverter, there are two DC connections for other inverter
Protection Systems:
Thermal protection, Overload protection, Over Voltage protection, Under Voltage protection, Low Voltage protection alarm Inverter comes with an LED light to denote the issue
9 varieties of protections:
1 circuit manufacturing
When the weight is short circuit, the inverter will quit working
2 High temperature manufacturing
When the use surroundings is stuffy, the warmth of the inverter can not be radiated The temperature is above the rated temperature, the inverter will stop operating
3 High voltage protections
The battery voltage is above the rated voltage of the inverter, the inverter will stop operating
4 Low voltage protections
The battery’s voltage falls in the course of the usage When it is less than the rated voltage, the inverter will routinely lower the enter voltage for the self defense
5 Surge protection
It can keep away from the DC high voltage’s surging attack upon the electronic ingredients inside
6 Overload protection
When the appliances’ power is higher than the inverter’s power, the inverter will quit operating for self defense
7 Over latest Protection
When the appliances’ latest is greater than the inverter’ current, the safety components on the board will be lower routinely for self protection
eight defense
When the appliance’s resistance is greater than inverter’s, the fuses on the socket will be mechanically bring to a halt for self defense
nine Reverse defense
It can avoid the accidents of burning the inverter if the superb and the destructive poles are reverse connected
The Resistive Load Applications and The Inductive Load Applications:
For resistive load applications:
If you would like the inverter to run the resistive load (like laptop, TV, electrical cooker, LED light), please desire the inverter with continual strength larger than the appliance&;s rated strength
For example, for the flexibility inverter with continual energy 2500w,it is suggested to run the applying with rated strength lower than 2500w It is better to use 80% of the rated energy
For inductive load applications:
If you need the inverter to run the inductive load (for equipment comparable to compressor, motor, water pump), please calculate the power of inverter 3 to 7 occasions larger than the rated strength of your appliance
Product Certification:
Durable and secure high quality with decades usage, our pure sine wave inverters are permitted by EMC checking out in Australia and CE certified 18 months guarantee
Product Packaging:
The Transportation:
For the small capacity, The inverter can be despatched by DHL, EMS, FedEx and e-EMS, it's going to take 3-12 days for shipping
If you need broad quantity, please contact with me concerning the transport task
Customer Service:
1 RELIABLE is your trusted companion for long term enterprise are the MANUFACTURER of the solar inverter We are chargeable for the standard of the inverter The inverter has ONE yr warrantly We present technical support and repair for the inverter the whole life
All inverters would be double tested earlier than shipment to be guaranteed in fresh condition and work completely
2 Returns for replace are accepted and must be initiated via the buyer within four days of receipt All return goods should be in their original situation Return delivery and handling payment might be on the buyer&;s expense first Please do touch with us for go back address, details and some other problems
3 We aren't accountable for any put off throughout delivery adding but now not limited to the customs package checking, strike, force majeure, etc
4 In case there is situation together with your order, make sure CONTACT US before leaving negative feedback Leaving unfavorable suggestions without communique is a contravention of suggestions coverage
5 Please leave us message in case you have any question, we are able to respond in 24 hours, thanks
How to decide a right inverter:
We accept the custom-made made inverter for every customer, please leave me a messages of your inverter specifications:
Leave me most of these specifications by way of sending me a message, in order that I could make sure of a fast shipping!
Our inverter is single part inverter, there may be only one enter voltage and output voltage for each inverter, the output voltage can't be splitted into smaller voltage Such because the 240V can not be splitted into 120V
1&;s your input voltage?12v or 24v or 36v or 48v or 72v or 110v?
(attention please: just one voltage could be choose! If the enter is 48v or 72v, the extra 10% payment can be needed, if the input is 110v, the additional 15% price can be mandatory If you need distant controller, we need extra 15 USD Please contact with me I&;ll exchange your price, or you will pay us by means of paypal)2&;s your output voltage? 100v or 110v or 120v or 220v or 230v or 240v?
3&;s your frequency? 50HZ or 60HZ?
4&;s your socket type? please look at the picture I connected and make a choice
