Description

• ShenStar XR502 Series 2 SBUS PPM RSSI Dual Antenna Micro Receiver for DSM-X/2 SFHSS Frsky-D8/D16 AFHDS-2A Radio Transmitters Features: 1) Super small size(10*14*2); 2) Super light(0); 3) With integrated 13dBm LNA; 4) Dual antenna; 5) Can be used on any flight management boards; 6) Dual antenna would be bent in any course and no broken; 7) Support RSSI output; 8) Support SBUS output and PPM(22ms) out put on the similar time; 9) F edition supports mixture protocol(D8 and D16); Binding operation: Press the binding switch after XR6OO receiver is powered, it enters binding mode after 2 seconds when the sluggish flashing purple LED turns to instant blinking Then bind the receiver consistent with the transmitter manual When the quick blinking purple LED turns to stable bright, it indicates binding is successful Variable RF Link technology Variable RF Link technology: When the receiver is just too close to radio(remote control), normally RF signal will be blocked and in the meantime lose management happens, Variable RF Link is born for solving the problem! As soon as Variable RF Link reveals that the receiver is coming close to radio, it will regulate LNA gain and PA output strength decrease to circumvent short distance control failure automatically; When Variable RF Link detects that the receiver is going distant from radio, it'll modify LNA achieve and PA output power larger to increase RX's working differ routinely RSSI signal output Two methods for RSSI signal output: 1) SBUS signal: RSSI sign output is at the No channel(AUX12) of SBUS; 2) PPM signal: RSSI sign output is on the No channel of PPM; Mixture protocol(only for XR502-F version): XR502-F edition can support both D8 and D16 FrSky protocol, customer can choose which one they want to apply while binding The constant bright blue LED, binding is be successful indicating RX is with D16 protocol; If the blue LED is off and binding is be successful indicating RX is with D8 protocol

•
•
•
•
•
