Description

• Parameters: 1 Rated power: 550W/750W/1100W/1500W/2200W 2 Rated voltage: AC 220V/110V 50-60Hz three Speed differ (RPM): 200-7000 (550W); 200-6500 (750W); 200-6000 (1100W); 200-5000 (1500W); 200-4500 (2200W) 4 Rated torque (Nm): 1 (550W); 2 (750W); 3 (1100W); five (1500W) five Installation size: 69mm 6 Shaft diameter: 15mm 7 Out shaft length: 27+15mm 8 Mounting thread: M6 by way of hole 9 Key slot: 5*5*20mm Features: 1 Support one-key forward and opposite rotation, help tender delivery (both start and stop ease) 2 The motor output shaft has 15mm thread, that are equipped with synchronous pulley and ER particular chuck, which is broadly used in belt sander, polishing machine, small lathe, milling machine, and so forth 3 Pure copper motor, stable strength and effective warmth dissipation 4 Strong anti-interference ability, low noise, with a number of protections reminiscent of overcurrent, overload and overvoltage Energy saving servo motor guide 1 Safety instructions: 1 This product calls for official body of workers to put in and debug: 1 It is necessary to guarantee reliable grounding of the system; 1 It is strictly prohibited to open the management field and motor hide when powered on; 1 Please be sure to turn off the ability when performing the ensuing operations: a) When putting in and repairing machines; 2 Instructions for utilizing the operation panel: 2 Purpose of every button: F : Enter parameter combination key Combined with other keys to go into parameter setting mode, error recovery key D: Direction switching The leading function is to switch instructions and ensure parameter settings + : Increase motor speed Adding keys to parameter and index values - : Reduce motor velocity Parameter and index price lower key 2 Adjustment system for technician mode parameters: a) Press and keep the "F" key while urgent the "+" key, and the display screen will show as P-00; b) Press the "+" or "-" keys to regulate the parameter number; c) Press the "F" key to enter the parameters, and the display will exhibit the parameter values; d) Press the "+" or "-" keys to adjust to the specified parameter value; e) Press the "D" key to save lots of the parameters and exit 2 Restore factory settings: While holding down the "F" key, press the "+" key once, and the display will reveal as P-00 Then, keep down the "D" key for 3 seconds and release it 3 Technician mode parameter table: P-02 Motor route 0: counterclockwise; 1: Clockwise P-04 Starting speed 200-800 rpm P-05 Acceleration pace 300-1350 P-07 Start switch 0-1 0: Knob delivery 1: Key beginning P-08 Brake operate 0-1 0: Brake off 1: Brake activated P-10 Automatic operating in 0: Ordinary sewing; 1: Automatic working in Turn off the ability and forestall Stop running in P-12 Acceleration time 4-120 Acceleration time P-14 Maximum latest limit 50-500 4 Fault handling: Error code Er03: Motor Hall or section line error Poor plug contact; The motor is not installed properly; Hall is broken Er04: Locked rotor protection Motor overload; The 4 core wires connected to the motor and electronic management have deficient contact Er05: Hardware overcurrent defense Motor overload; The sign line has poor contact or is broken Er07: Serial communique timeout error The connection cord between the display screen and the motherboard is poor or the motherboard is damaged

•
•
•
•
•
