HP350BF Blue Light Strobe Spectrum Analyzer is a brand new era of sunshine source mild colour trying out software with 5-inch IPS contact display It adopts the integration of advanced micro spectrometer, embedded working components and microcomputer technology to facilitate on-site testing, making the examine extra handy and simple, and extra in line with the positioning Parameter check analysis and verification of application situations
leading application:
(1)(Based on standards:
Blu-ray: CIE S009, IEC/EN62471, IEC62471-2, IEC62778, GBT20145, etc;
Lighting: GB55016-2021 Architectural Lighting CIE1931, CIE1960, CIE1976, GB/T5700-2008, GB/T 36979
Strobe: ▲Basic measurement, ▲IEEE PAR 1789 "IEEE Std 1789TM-2015" GB/T 18910
GB/T 18205-2012, GB/T 36876-2018, GB/T5700-2008, JGJ 153-2016, TY/T 1002, GB/T5699-2017 GB/Z26212-2010/CIE, GB/J50034-2013
(2) Basic measurement functions:
Main measurement parameters: retinal blue light danger (300nm-700nm), retinal thermal danger (380-800nm), susceptible visual stimulation retinal thermal danger (780nm-800nm), color coordinates (x, y, u, v, u&;, v&; ) wavelength, shade temperature (CCT), illuminance (lx), shade rendering index (Ra, Ravg), colour tolerance (SDCM), coloration purity (Purity), colour saturation (Rg), shade constancy (Rf), color Quality index (CQS), light/dark visible ratio (S/P), transmittance, flicker index, flicker percentage, modulation depth, stroboscopic risk level, and many others
(1) Product benefits
1 Communication method: USB
2 Multiple exhibit methods: computer, IPS touch display
3 The shape conforms to the ergonomic handheld design and is handy and convenient to apply
(2) Core devices
1 The TCD1304DG CCD detector is coated with antireflection coating to attain a quantum performance curve in the illuminated discipline with a band fluctuate of 350-800nm
2 Enhanced coating grating: variety of lines: 1200 lines, blaze wavelength 300nm, spectral reaction 200-1100nm
three Enhanced collimating lens and focusing lens
four 16-bit high-speed AD sampling
5 High-precision and steady computing circuit
6 High-precision optical path, small stray light, removal of high-order diffraction spectrum (equipped with cloud spectrum filter out system)
(3) Test advantages
1 Comparison test, transmittance test, parameter comparison (rolling and locking modes)
2 Regular trying out and steady saving (light attenuation examine verification would be performed)
three The wavelength is adjustable for easy query (a unmarried band is extra handy for viewing and analysis)
4 One-click trying out and one-click sharing of APPs and mini-programs (moments, Weibo, forums, etc)
five Test end result correction (test result coefficient correction for various situations and environmental changes)
2 Optical direction characteristics (fiber spectrometer structure)
1 Multiple optical inputs: cosine correction probe, SM905 optical fiber (with cosine correction)
2 Wavelength range: 350-800nm
three Spectral resolution: ±0, wavelength resolution:
four Photometric linearity ±0%
five Stray light: <0%
6 Photometric probe cosine correction: error ≤5%, nonlinearity ≤1%
7 Absolute price of fatigue error: ≤2%
8 Long wave response error: ≤15%
nine Relative indication error: ±5%
10 Zero cost error: ±1% (FS)
eleven Measuring range: automatic error ±1%
12 High-speed information collection, integration time: millisecond point
thirteen Focal length 42, symmetrical non-crossed H-T optical path
14 Communication method: USB communique
15 Overall dimensions: 186mm*80mm*21
16 Using progressed micro-spectrometer technology, the verify accuracy is increased than that of common probes;
17 Can be linked to computer software for testing, and might be linked to pc to print check reports;
18 Color LCD display, good graphic and text interface, can show spectral waveforms and coloration tolerance ellipse diagrams;
19 5-inch IPS contact display
