• Product features: 1 High-speed deciphering and responsiveness 2 Compact, lightweight, ergonomic and comfy to handle three Excellent durability: Dustproof and waterproof IP54 and may face up to drops to concrete at a peak of one Parameters: Type:U20 Scan mode:Key trigger/auto-sensing/continuous scanning Interface type: USB Prompt mode: Buzzer, LED light How it is set up: Manually scan the setup codes one after the alternative Housing material : ABS + PC Cable standard: Straight line 1 Exterior dimensions: 160mm×66mm×95mm(product); 195mm×105 mm×80mm(packaging) Sensors: CMOS Resolution: 640*480 Light source: White LED Scan angle: ± 60°, ±60°, 360° (elevation, declination, rotation) Scan rate: one hundred twenty fps Field of view : 48° (H) x 30° (V) Printing contrast: Minimum 15% Decoding kind: 1D: EAN13, EAN 8, UPC-A, UPC-E0, UPC-E1, Code128, Code39, Code93, Interleaved 2 of 5, Industrial 25, Matrix 2 of 5, Code11, CodeBar, MSI, RSS-14, RSS- Ltd, RSS- Exp, Standard 2 of 5, Plessey, GS1 Composite 2D: QR Code, Data Matrix (DM), PDF417, MaxiCode, Aztec Code, assist cellular screen reading Minimum resolution: 1D code 3; QR code 10MIL Depth of field QR (15mil) 30~210mm QR charge code (mobile code) 80~550mm Data Matrix (10mil) 30- 140mm PDF 417 (6) 50- 120mm EAN-13 (13mil) 50~280mm Code 39 (8mil) 30- 190mm Code 128 (15mil) 80~320mm Input voltage: DC5V ± 10% Current: Working: 350 mAh; Standby: 130 mAh Environment parameters: Temperature 0°C-50°C (working); -40°C~+60°C (storage) Humidity: 5%-95% non-condensing Ambient brightness: Max,000 Lux (fluorescence) Seismic resistance: It can stand up to a drop in the air of 1 Note: 2D barcode scanner,it also well suited with scanning 1D codes

•
•
•
•
•
