• 2019 LXC706 Completely replaced dse702 diesel generator auto birth management Description---------- 1 The Module LXC706 is an small Automatic Engine Control Module It selects three styles of operating state(Manual, Auto, Stop), can go panel gentle touch buttons artificially start/stop genset, also can through distant start signal enter automated beginning generator, and might detect fault (low oil pressure, high water temperature, emergency give up alarm, over speed) routinely disconnect gas relays and prevent electromagnet to electrical suction shut Panel LED indicator fault state, provide genuine and advantageous fault alarm sign 2 FEATURES *Emerald green backlight, generator parameters are clearly seen throughout the day and evening *LCD icon display alarm, alarm news is visual, universal *On the LCD digital show quite a lot of generator parameters *The PC panel with durable, waterproof *The management panel, smooth realization of generator start stop, cut the person connection *All parameters could be set at the panel, handy debugging and maintenance * Set all the configuration parameters and tracking computer by way of USB connection *Ultra small size, appropriate for small generator, clever control is particularly compatible for small gasoline generator *Equipped with a shockproof rubber ring, can achieve waterproof and shockproof panel *Install the assembly, flame retardant ABS shell, pluggable terminal, embedded installation, compact structure, convenient installation 3 PERFORMANCE *The strength delivery a wide range (8~35) VDC, can adapt diverse starting battery voltage environment *The microprocessor because the core, for the LCD screen show icon symbols, mild contact keys *With low oil pressure, high water temperature, over speed, and emergency stop, delivery mess ups and so on protection and directions *Can discover and reveal of strength are: power voltage V, power frequency Hz, engine temperature ºC, oil stress kPa, speed rpm, total operating time H, the battery voltage V, gas level% *voltage of the generator, battery voltage, speed, temperature, pressure, liquid level sensor threshold can be set, can obtain the following alarm or warning: low oil pressure, water temperature, cylinder temperature high, speeding, much less speed, emergency stop, failure to start, stop, failure of power voltage is too high, too low, power frequency is just too high or too low, the battery voltage is just too high low, low fuel point *With idle pace control and ETS solenoid operate With three working state: manual, automatic, give up *Through the application atmosphere of controllers would be set to the engine controller (not want the power voltage input), compatible for management of pump unit *Panel with a purple mild emitting diode (LED) show and alarm repute *A sort of temperature, pressure, oil level sensor can be utilized directly, and may custom parameters: Temperature, stress sensor, respectively, and temperature, strain alarm in parallel, in providing the electronic quantity at the same time broaden the extent of defense *Many profitable beginning condition (rotational speed sensor, oil pressure, energy generation) can choose *Four constant relay output( fuel oil output, starter output, to stop the output, Idle pace output) *A programmable output, could be set to public alarm output, stop failure output,preheating output or idle pace management output operate *Allow the user to alter the environment of parameters, and memory in the inner FLASH memory, will now not be misplaced in the formula when the ability is off, the controller from the entrance panel of the controller All the parameters would be adjusted, or in the course of the USB interface by way of the PC machine USB power delivery controller, through monitoring application for parameter surroundings Working Voltage DC8 0V to 35 0V, Continuous Power Supply Overall Consumption standby mode: 12V:0 24V:0 working: 12V:1W 24V:1 AC voltage Input Single section 2 Wire 15V AC - 360 V AC (ph-N) Alternator Frequency 50/60Hz Speed Sensor Voltage 1V --24V(effective value) Speed Sensor Frequency most 10kHz The maximum total run time 99999 hours (After the decimal level is 1/10 hours,Six minutes once changes) Start Relay Output 1Amp DC28V B+ energy delivery Fuel relay output 1Amp DC28V B+ energy supply Shutdown relay output 1Amp DC28V B+ strength supply Idle pace relay output 1Amp DC28V B+ power supply Programmable relay output 1Amp DC28V B+ strength supply Switch input port After B - high quality Overall Dimensions 97mm x 78mm x 44mm Panel Cutout 78mm x 66mm Working Conditions Temperature:(-25~+70)ºC Relative humidity:(20~90)% Storage Conditions Temperature:(-30~+80)ºC Protection Level IP55:When water resistant rubber seal put in between the controller and panel fascia IP42:When water-resistant rubber seal is not installed between the controller and panel fascia Insulation Intensity Object:input/output/power Quote standard:IEC688-1992 Test way:AC1/1min leakage current:1mA Weight 0

•
•
•
•
•
