• 1800W 40A 1500W 30A 1200W 20A DC-DC Boost Converter Step Up Power Supply Module 10-60V to 12-90V Adjustable Voltage Charger Product promoting point: 1 Using fantastic materials, the quality is guaranteed 2 Fan blade warmth dissipation is adopted, the warmth dissipation impact is terribly good, and the output strength is higher 3 The temperature-controlled fan adopts hydraulic bearing fan, which has done a good stability in noise and heat dissipation When the burden is light, the fan doesn't flip When the load temperature reaches about 60 degrees, the fan routinely rotates Can effectively cut noise and prolong provider existence four The leading energy tube insulation board is manufactured from nice alumina, and the thermal conductivity is 10 times that of standard insulation pads five Oversized ferrosilicon aluminum magnetic ring, using four 1 pure copper enameled wires, low calorific price and high performance 6 With fixed current function, it may be used for vehicle battery boost, battery charging, etc parameter: Working characteristics: Output power: 1800W Input voltage range: 10V-60V Output voltage range: 12V-90V Input current: 40A Output current: 22A Conversion efficiency: 48V to 60V 8A (98 %) 48V to 72V 8A (98%) 48V 84V 8A (97%) Charge Regulation: 10% to 50% payment (72V output) Temperature coefficient: 50% load Ripple and Noise: 20MHz bandwidth (48V-72V 4A) 100mVp-p Switching frequency: VIN = 48V VO = 72V 4A (110khz) No-load current: VIN = 48V VO = 72V (18mA) Input opposite protection: sure Storage humidity: 95% Operating temperature: -20 sixty five °C Storage temperature: -40 a hundred twenty five °C Operating Temperature Rise: 48V to 60V 5A (45 °C) Overheating Protection: 60°C Wiring method: input, output (solderless, terminal block) Cooling method: strong air cooling Package list: Boost Converter*1 Module parameters: Module name: 1200W enhance fixed recent module Module nature: non remoted enhance module (b0ost) Input voltage: dc10-60v Input current: 20A (max) (when the enter voltage of fan cooling is 12-24V, the enter recent can reach 25a) Static working current: 15mA (when 12V rises to 20V, the higher the output voltage, the higher the static latest will increase) Output voltage: 12-83v consistently adjustable (the default output is adjusted to 19v for shipment, please specify if it needs to be adjusted to other voltage values If there is a multimeter, the customer can alter it through himself) 12-83v constant output (for batch customers) Output current: 18A Max greater than 10A, please make stronger warmth dissipation (related to enter and output strain difference, the larger the pressure difference, the smaller the output current) Constant current range: 0 (+/-0) Input anti reverse connection: Yes (150A strength MOS anti reverse) Low battery protection: Yes (9-50v adjustable) Temperature management fan: Yes (turn at the fan over 55 °) Operating temperature: -40~+85 ℃ (please strengthen heat dissipation when the ambient temperature is too high) Operating frequency: 150kHz Conversion efficiency: 92%-97% (efficiency is said to input and output voltage, current and voltage distinction Low voltage difference and excessive efficiency) Input overcurrent protection: Yes (if the input exceeds 25A, will probably be automatically safe and the ability delivery are usually not boosted) Short circuit protection: with (input 30A fuse) double brief circuit protection, it's more secure to apply Input opposite connection protection: Yes (150A energy MOS tube is anti opposite It could be reversed for a long time) Installation method: four 3mm copper columns Wiring mode: wiring terminal (please use excessive latest natural copper wire) Module size: 130mm long, 52mm broad and 53mm high Module unit weight: 300g Output power: = input voltage *20a, for example: enter 12v*20a=240w the maximum power at input 12V is 240W Input voltage *20a e input 24v*20a=480w, i essentially the most energetic strength is 480W when input 24V Note: the utmost energy is 240W when 12V is input, 480W when 24V is input, and 720W when 36V is input Output voltage / output recent law / enter low battery defense regulation Voltage regulation: regulate the "v-adj" potentiometer on the output finish (marked in the figure below) with a slotted screwdriver when the ability is turned on and no-load Turn it up clockwise and turn it down counterclockwise Due to the large capability of the output capacitor, the response can be slow when the output voltage is adjusted from excessive voltage to low voltage The adjustment differ of Jianyi is smaller (the default output voltage is adjusted to 19v for shipment) Current regulation: adjust the "a-adj" potentiometer counterclockwise for roughly 30 turns, set the output latest to the minimum, connect the LED or current, and modify the "a-adj" potentiometer clockwise to the current you need For battery charging, after the battery is discharged, it is connected to the output and changed to the present you would like When it is used for charging, it ought to be adjusted after the battery is discharged (by default, the output power is adjusted to 3A for cargo Do now not alter the current through short-circuit output The circuit structure of the increase module can't be adjusted through short-circuit, Input low battery protection regulation: low battery protection is mainly used to prevent the battery from over discharging when the enter power delivery is battery, and the low battery voltage will harm the ability module and battery For example, set the low battery protection of 12V battery Connect a 10V voltage on the enter finish of the power module and use a slotted screwdriver to regulate rv1 (increase the safety voltage clockwise and reduce the safety voltage counterclockwise) until the UVLO gentle is on At this time, the low battery protection voltage is 10V detailed list: 1*1200w enhance constant latest module 20A

•
•
•
•
•
