• Features: 1 protection 2 reliability 3 to apply and set up 4 differ of use five wiring Introduction: Improved Version: Micro DC Brushless Motor Drive Board The formerly offered brushless motor pressure board can easily burn out the pressure chip when the motor twine is in deficient contact, wrongly connected, overloaded, or quick circuited at the output end However, the enhanced drive board will no longer burn the chip no matter how the motor twine is wrongly connected, how broad the burden is, or when the motor twine is brief circuited, it can be operated with peace of mind This pressure board can power micro 3-wire or 4-wire Hall free brushless motors such as harddrive brushless motors and optical drive brushless motors The motive force board has voltage opposite protection, overcurrent protection, brief circuit protection, clear-cut wiring, and is terribly fear loose to apply The hard drive motor can rotate with a voltage of 7-12V, and the better the voltage, the quicker the speed, with a most velocity of round ten thousand revolutions How to identify the common ports of a 4-wire motor: Measure these 4 terminals utilizing the resistance * 1 range of a multimeter If one terminal has the smallest and equal resistance value to the opposite three terminals, then this terminal is the COM terminal, which also is the typical terminal The driving force board automatically acknowledges 3-wire or 4-wire brushless motors, and 4-wire brushless motors can be disconnected from COM cables Parameters: Drive voltage: DC 7-12V Working current: ≤ 1 Speed regulation range: 0% -100% [Phase conversion control] Yes [Voltage reverse protection] Yes [Overcurrent protection] Yes [Short circuit protection] Yes Attention: After quick circuit overcurrent defense for the brushless power board, the power indicator gentle will turn off At this time, the power delivery to the pressure board needs to be bring to an end After addressing the reason for overcurrent, the ability delivery to the force board can be restored Once the LED power indicator gentle is on, it'll work usually Package include: 1 * Driver board

•
•
•
•
•
