Description

• 1 Photosensitive film: (1/4inch ) 2 The easiest tremendous pixel: 1280(H)x720(M) three Lens Size: 1/4 inch (4: 3) 4 Pixel Size: three 5 Image area: 5 x 4 6 Output picture format: MPEG/YUV2 (YUYV) 7 Supported resolutions and body rates: 1280x720@30fps MJPEG 1280x720 @10fps Yuv 800x600 @30fps MJPEG 800x600 @15fps Yuv 640x480 @30fps MJPEG 640x480 @30fps Yuv eight Camera board assembly technology: SMT nine Focus: Fixed 10 Center definition: 600LW/PH (Center) eleven Signal-to-noise ratio: TBD 12 Dynamic range: TBD thirteen Sensitivity: 1/lux-sec@550nm 14 Minimum illumination: 0 15 Shutter type: Electronic rolling shutter / Frame exposure sixteen Interface type: USB 2 High Speed 17 Automatic publicity control AEC: supported 18 Automatic white balance AEB: supported 19 Automatic gain control AGC: supported 20 Adjustable parameters: brightness/contrast/color saturation/hue clarity/gamma/white balance/backlight contrast/exposure 21 specifications: Size: 1/4 Focal length: 2 Aperture F2 diagonal:77° Interface M12xP0 Colour:Black Material:PC+Plastic Package Contents: five x a hundred Degrees OV9732 Camera Module five x 2m USB Cable Only the above package content, different merchandise are not included Note: Light reflection and diversified displays could cause the colour of the article within the picture somewhat diverse from the real factor The size allowed error is +/- 1-3cm

•
•
•
•
•
