Description

• CPU AMD AM4 Socket for AMD Ryzen™ 5000 Series/ 5000 G-Series/ 4000 G-Series/ 3rd/2nd/1st Gen AMD Ryzen™/ second and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics/ Athlon™ with Radeon™ Vega Graphics Processors * * Refer to www for CPU support record Chipset AMD B450 Memory 3rd/2nd/1st Gen AMD Ryzen™/ 2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics/ Athlon™ with Radeon™ Vega Graphics Processors 4 x DIMM, Max 128GB, DDR4 4400(O)/3533(O)/3466(O)/3200(O)/3000(O)/2800(O)/2666/2400/2133 MHz Un-buffered Memory * Dual Channel Memory Architecture ECC Memory (ECC mode) help varies through CPU * Refer to www for the Memory QVL (Qualified Vendors Lists) Graphic Integrated Graphics within the second and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics/ Athlon™ with Radeon™ Vega Graphics Processors 1 x DisplayPort 1 1 x HDMI 2 *Graphics specs might differ between CPU types Multi-GPU Support Supports AMD 2-Way CrossFireX Technology Expansion Slots 3rd/2nd/1st Gen AMD Ryzen™ Processors 1 x PCIe 3/2 x16 (x16 mode) 2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors 1 x PCIe 3/2 x16 (x8 mode) Athlon™ with Radeon™ Vega Graphics Processors 1 x PCIe 3/2 x16 (max at x4 mode) AMD B450 chipset 1 x PCIe 2 x16 (x4 mode) *1 1 x PCIe 2 x1 Storage Total helps 2 x M slots and 4 x SATA 6Gb/s ports 3rd/2nd/1st Gen AMD Ryzen™/ second and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics : 1 x M socket 3, with M Key, Type 2242/2260/2280 (PCIE 3 x4 and SATA modes) storage devices support Athlon™ with Radeon™ Vega Graphics Processors : 1 x M socket 3, with M key, type 2242/2260/2280 storage instruments help (SATA mode) 3rd/2nd/1st Gen AMD Ryzen™/ 2d and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics/ Athlon™ with Radeon™ Vega Graphics Processors : Support Raid 0, 1, 10 AMD B450 chipset : 1 x M socket 3, with M key, form 2242/2260/2280/22110 garage instruments support(PCIE 2 x4)*2 four x SATA 6Gb/s port(s), LAN Realtek RTL8125B 2 Ethernet TUF LANGuard Audio Realtek ALC S1200A 7 Surround Sound High Definition Audio CODEC - Supports : Jack-detection, Multi-streaming, Front Panel Jack-retasking, up to 24-Bit/192kHz playback Audio Feature : - Exclusive DTS Custom for GAMING Headsets - Optical S/PDIF out port(s) at again panel - Audio hide - Audio Shielding - Dedicated audio PCB layers - Premium Japanese audio capacitors USB Ports Rear USB Port ( Total eight ) 2 x USB three Gen 2 port(s)(1 x Type-A +1 x USB Type-C®) four x USB 3 Gen 1 port(s)(4 x Type-A) 2 x USB 2 port(s)(2 x Type-A) Front USB Port ( Total 6 ) 2 x USB 3 Gen 1 port(s)(2 x Type-A) 4 x USB 2 port(s)(4 x Type-A) Software Features ASUS Exclusive Software Armoury Crate - Aura Creator - Aura Sync - AI Noise-Canceling Microphone AI Suite 3 - Performance And Power Saving Utility TurboV EVO EPU Digi+ VRM Fan Xpert 2+ - EZ update TUF GAMING CPU-Z AI Charger ASUS Turbo LAN DAEMON Tools DTS Custom for GAMING Headsets Norton Anti-virus utility (Free Trial for 60 days) WinRAR UEFI BIOS ASUS EZ DIY - ASUS CrashFree BIOS three - ASUS EZ Flash 3 - ASUS UEFI BIOS EZ Mode ASUS Special Features ASUS TUF PROTECTION - ASUS DIGI+ VRM (Digital power design with DrMOS) - ASUS Enhanced DRAM Overcurrent Protection - ASUS ESD Guards - TUF LANGuard - ASUS Overvoltage Protection - ASUS SafeSlot - ASUS Stainless-Steel Back I/O ASUS Q-Design - ASUS Q-DIMM - ASUS Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device [yellow green]) - ASUS Q-Slot ASUS Thermal Solution - Aluminum heatsink design ASUS EZ DIY - BIOS FlashBack™ button - BIOS FlashBack™ LED - ProCool AURA Sync - AURA RGB headers Back I/O Ports 1 x PS/2 keyboard/mouse combo port(s) 1 x DisplayPort 1 x HDMI 1 x LAN (2) port(s) 2 x USB three Gen 2 (teal blue) (1 x Type-A+1 x USB Type-C®) four x USB 3 Gen 1 (blue) Type-A 2 x USB 2 1 x Optical S/PDIF out five x Audio jack(s) 1 x BIOS FlashBack™ Button(s) Internal I/O Ports 1 x CPU Fan connector(s) 1 x CPU OPT Fan connector(s) 2 x Chassis Fan connector(s) 2 x Aura RGB Strip Headers 1 x USB three Gen 1(up to 5Gbps) connector(s) support(s) extra 2 USB 3 Gen 1 port(s) 2 x USB 2 connector(s) support(s) extra four USB 2 port(s) 1 x M Socket three with M key, kind 2242/2260/2280 garage instruments assist (SATA & PCIE three x 4 mode) 1 x M Socket three with M key, variety 2242/2260/2280/22110 storage instruments support(PCIE 2 x4) 1 x SPI TPM header four x SATA 6Gb/s connector(s) 1 x 24-pin EATX Power connector(s) 1 x 8-pin EATX 12V Power connectors 1 x Front panel audio connector(s) (AAFP) 1 x Clear CMOS jumper(s) 1 x System panel connector 1 x COM port header 1 x Speaker connector

•
•
•
•
•
