Description

• Working voltage: 6-20V (limit 24V) Drive current: rated 30A plus air cooling 50A Maximum power: 1000W Overcurrent protection: Yes Locked- protection: Yes (after locked-, the current will routinely drop and run at intervals) Over-temperature protection: Yes (over-temperature energy is halved) Maximum speed: 224000 RPM (2 pole motor), 74000 RPM (6 pole motor), 40000 RPM (12 pole motor), 35000 RPM (14 pole motor) Precautions: 1 Reverse connection of the nice and unfavorable poles of the ability supply at the motherboard will trigger everlasting injury to a couple of the chips at the board ( latest will not paintings for a couple of seconds) 2 There is sampling over-current protection on the output of the motor during ordinary operation Because the flexibility and latest of the module are very , please do not artificially short-circuit the module when the module isn't always operating usually Once the short-circuit, the circuit may be burnt and the tube may burst, the first wiring test Please test with low recent and occasional voltage After ok, hook up with high latest and high voltage Since it is a board module, please eavesdrop on the insulation of the wiring head It is exactly forbidden to touch the board elements 3 Do now not connect the motor that is for sure inconsistent with module voltage, current, or power, to bypass inexplicable harm Model Number: Motor Driver Board color:As shown Material:Plastic + Metal Package Contents: 1 x DC 6-24V 1000W BLDC 3-Phase Brushless Motor Driver Only the above package content, different products are not included Note: Light and different exhibits can cause the colour of the article in the photo a bit various from the real thing The dimension allowed error is +/- 1-3cm

•
•
•
•
•
