Description

• 6022BECost-effectiveness, 20MHz bandwidth 2CH scope, 48MSa/s pattern rate, with 2pcs probes; Standard USBXI (TM) interface, easyly inserts into USBXI (TM) housing to make up a mix tool 6022BL 20MHz Bandwidth; 48MSa/s Sample Rate; 16 Channels Logic Analyzer; Excellent business design-the same anodised aluminium casing as iPad, which is not only exquisite and tasteful but additionally enormously enhanced the hardness of aluminum alloy surface, and has good warmth resistance and strong wearability Standard USBXI (TM) interface, easyly inserts into USBXI (TM) housing to make up a mixture device The main distinction between 6022BE and 6022BL is that the 6022BL with 16Channels Logic Analyzer Car-detector, 6022BE with out Features: * Excellent business design-the same anodised aluminium casing as iPad, which isn't just exquisite and tasteful but in addition drastically enhanced the hardness of aluminum alloy surface, and has nice heat resistance and strong wearability* Standard USBXITM interface, easily inserts into USBXITM housing to make up a combination instrument* USB2 interface, no exterior strength supply required, clean to use* Be appropriate for notebook computer, product line maintenance, be used smoothly on business* Dimensions (mm):205(L) x120(W) x35(H), be carried easily* High performance, 48MS/s real-time sampling, 20MHz Bandwidth,* Operating System: Windows 7, Windows NT, Windows 2000, Windows XP, VISTA* 23 size functions, PASS/FAIL Check, be appropriate for technical application* Waveform average, persistence, intensity, invert, addition, subtraction, multiplication, division, X-Y plot* Save waveform in the following: textual content file, jpg/bmp graphic file, MS excel/word file* FFT* One laptop can join many DSO, increase channel easily* Labview\VB\VC Second Design occasion Hantek 6022BE Specifications: Model 6022BE Channel 2 Channels Bandwidth 20MHz Input Impandence 1MΩ 25pF Max Sample fee 48MS/s Vertical resolution 8Bit Gain range 20mV-5V, 8Steps DC accuracy ±3% Coupling DC Timebase differ 1ns-9000s, 39 Steps Vertical adjustable Yes Input protection Diode clamping X-Y Yes Trigger Mode Auto, Normal and Single Trigger Slope +/-+/- Trigger point adjustable Yes Trigger Type Rising edge, falling edge Trigger Source CH1, CH2 Pre/Post trigger 0-100% Sampling alternative YesYes Waveform Display port/line, waveform average, persistence, intensity Network Open/Close Vertical modeVertical mode CH1, CH2, Dual, ADDCH1, CH2, Dual, ADD Cursor measurement Yes Math FFT, addition, subtraction, multiplication, department Cursor Frequency, Voltage Accessories S/W CD, probes, manual, USB twine 3 Operating system: Windows 7, Windows NT, Windows 2000,Windows XP, VISTA 4 Design Supply DEMO code(VC、VB、LABVIEW) and technical support Hantek 6022BL Specifications: Model Hantek6022BL Oscilloscope Features Bandwidth 20MHz Channel 2(Digital)+16(Logic) Sample Rate 48MSa/s Memory Depth 1M Rise Time 17 Time Base Precision ±50ppm Time Base Range 4ns/div-1h/div (Step by1-2-4) Input Impendence 1MΩ 25pF Input Sensitivity 20mV/div～5V/div Vertical Resolution 8Bit Vertical Position Range 20mV ~ 5V/div @ x1 probe; 200mV ~ 50V/div @ x10 probe; 2V ~ 500V/div @ x100 probe; 20V ~ 5KV/div @ x1000 probe DC Accuracy ±3% Bandwidth Limited 20MHz Trigger Type Edge, Alternative Trigger Source CH1, CH2 Math +,-,x,÷,FFT, Invert Cursor Measurement Cross, Trace, Horizontal, Vertical Auto Measurement Vpp, Vamp, Vmax, Vmin, Vtop, Vmid, Vbase, Vavg, Vrms, Vcrms, Preshoot, Overshoot, Frequency, Period, Rise Time, Fall Time, Positive Width, Negative Width, Duty Cycle Logic Analyzer Features Channel 16 Max Impendance 1MΩ(C=7) Max Voltage 0V~5 Max Sample 48M Bandwidth 10MHz Compatible Input TTL, LVTTL, CMOS Memory Depth 1M/CH General Features Power USB Port Demensions 200mm x100mm x 35mm Weight zero Standard Probe 2 x PP80 Make notice ,please: There have new design for 6022BE, New variety is Black conceal case, previous sort is gray conceal case, these 2 sort will ship in random, please be aware that before order

•
•
•
•
•
