Description

• Adopting ICL8038 and high-speed operational amplifier, with higher accuracy;It can output sine/triangular/square wave/forward and opposite sawtooth waveforms; Frequency range: 5Hz~400kHz; Duty cycle range: 2~95% (adjustable); Support twin power amplifiers with out blockading capacitors, guaranteeing excessive and coffee frequency signal distortion; Adjustable frequency and amplitude;Frequency adjustment has coarse and positive tuning functions;All are through-hole components, clean to put in Different batches could have diversified appearance, which doesn't affect use on the batch, the colours of electronic components/knobs, and many others may be different, which doesn't influence use Parameter: Power delivery voltage: 12V~15V Frequency range: 5Hz~400KHz (adjustable) Duty cycle range: 2~95% (adjustable) Low distortion sine wave: 1% Low temperature drift: 50ppm/° C Output triangular wave linearity: 0% DC bias range: -7~7 Output amplitude range: 0~11VPP (working voltage 12V) Interface Description: 1 SQU: Output rectangular wave 2 SIN/TA: Output sine wave or triangular wave 3 GND: Grounding four Potentiometer function: 1) Duty cycle: Adjusting the duty cycle fluctuate 2) Frequency regulation: Adjusting the frequency 3) Signal adjustment: Signal DC bias adjustment 4) Amplitude adjustment: sine wave, triangular wave, sawtooth wave amplitude modulation Pre purchase instructions: This equipment (loose parts) isn't a executed product and is simply used for clinical research and experiments This equipment isn't compatible for customers who require performed merchandise Assembling and debugging the kit (loose parts) requires corresponding data and skills Colour:Black Material:FR4+ digital components Package Contents: 1 x signal generator DIY kit with out shell Only the above equipment content, other products will not be included Note: Light reflection and different reveals could cause the color of the item in the photograph a little diversified from the genuine thing The measurement allowed error is +/- 1-3cm

•
•
•
•
•
