Description

• Product parameters Color: golden Condition: one hundred pc fresh Item type: Motor Controller Material: Aluminium alloy Voltage: 36V/48V/52V Weight: Approx 285g Power:350W-400W Current limit: 12A-18A What is a Three-mode controller? Quiet start(Except for special circumstances) solid strength and gear saving The three-mode controller is a sine wave controller It can operate in 3 modes, sine wave mode, sq. wave mode, and no hall mode (that is, it can be used and not using a hall sensor) The mode can't be selected, the default is sine wave mode When the corridor sensor is damaged it's going to automatically change to square wave mode Runs no-Hall mode when no Hall sensors are related Suitable for in-wheel motors motor, and so on Tips: Applicable to a variety of motors, yet only in-wheel motors with Hall sensors can use sine wave mode When working different motors, it'll mechanically swap to square wave mode or no Hall mode Installation Instructions Step 1 Connect wires 1, 2, 3, 9, 12 Step 2 Connect the No 11 cord with the motor suspended (Note: the motor ought to be within the overhang position for docking cord )Step three The motor will perform a forward/reverse state (If there's a reversal you could disconnect the 11 cord and reconnect it) Wait 10 seconds within the ahead state to complete studying 4 Make the wiring connections in line with the automobile 6-tube sinusoid controller Line Description Line characteristic particulars 1 Motor part twine 2 cord 3 change four Phase line velocity size 5 One-line conversation agreement 6 Three-speed moving 7 Anti-theft signal eight Anti-theft energy delivery 9 Hall sensor 10 Hall speed check 11 Intelligent studying line 12 Throttle 13 Reversal 14 15 High level braking 16 Low level braking 17 Sine wave model only can work with corridor sensored brushless DC motor If motor doesn&;t have corridor sesnor or hall sensor is harm is sq. wave controller Automatically identify voltage 36V~52V One-line instrumentation provides extra adaptability, about 80% In terms of hardware: thicker aluminum shell, higher warmth dissipation The motherboard solution is best Power tubes, capacitors, copper bars, etc are larger Suitable Motor Phrase Angle: Auto recognition Suitable for: electrical bicycle, scooter,Electric Boost bicycle and many others Package List: 1 x Brushless Controller How do I prefer an ebike controller? Important Note: the controller&;s voltage ranking must match your battery and motor If you purchase a non-programmable controller, ensure that it&;s energy and voltage matched with the power and voltage of the motor If the motor voltage is 36V, then the voltage of the controller must be 36V What does an ebike controller do? What is the operate of an electric motorcycle controller? The core function of an electrical motorbike controller is to take all of the inputs from all of the electrical ingredients ( throttle, pace sensor, display, battery, motor, etc) after which decide what should be signaled in go back to them (motor, battery, display)

•
•
•
•
•
