Description

• Note:Only Electronic Counter , Not Include different Accessories Feature: 1 five digit large-screen LCD display, wide and clean 2 Use an ordinary AA Batery, no exterior energy supply, and easy battery replacemen 3 Press the PAUSE button to pause/count, press the PAUSE button again, and resume counting four Input adopts traditional touch signal, simple and handy to pick sensor, correct and reliable counting five The best counting speed: 20 times/second, 1200 times/minute 6 Clear: Panel/external use Technical Parameters: Power supply: 1 -- AA battery (For safe delivery, not included) Counting range: 0---99999 Counting the highest frequency: 20HZ Counting minimum pulse width: 10mS Contact maximum resistance: ≤ 10KΩ Contact disconnection minimal resistance: ≥ 500KΩ Clear method: panel/external Clear the minimal pulse width: 0 seconds Ambient temperature: -5--40°C Dimensions: 64*38*38mm Opening size: 61*36 mm How to use: Start counting: Counting terminal input contact signal, the counter starts counting Pause counting: Press the PAUSE button to pause the counting; press the PAUSE button back to resume counting Clear the panel: Press RESET directly External clear: clear the exterior touch of the terminal and clean it directly Package include: 1 * Electronic Counter (Not incorporated Battery for safe delivery)

•
•
•
•
