Description

• 10 MPPT Hybrid Solar Inverter 48V Build-in MPPT 160A 230VAC Solar Charge Controller Dual PV Input Solar Inverter Features 1 sine wave solar inverter(on/off Grid) 2 strength ingredient 1 3 out there for lOS and Android 4 running with out battery 5 recovery to manufacturing facility Settings 6 Lithium battery automatic activation 7 160A MPPT photo voltaic charger 8 PV enter voltage range(90~450VDC) 9 anti-dusk kit for harsh surroundings 10 battery payment design to optimize battery existence eleven button 12 output 2 AC Output operate thirteen with BMS specs What is 2AC out function? when there is no Main/AC IN/GRID INPUT ,and the battery less than the setted voltage the key AC out will bring to a halt automatically, the battery or pv only offer power for the second one AC out What is the BMS model? Difference between BMS and with out BMS: If the battery has BMS, after plugging within the BMS, the inverter and the battery will speak and automatically adjust the charging voltage cut-off voltage and different parameters, and diverse parameters may be adjusted at any time per the condition of the battery, that may be the next point for the life of the battery and the security of use Question & Answer Q:Whats the Rated output power ? A:Its 10200W Q:Whats the max price foreign money for battery ? A:Its 160A Q:Whats the MAX DC PV Input? A:Its 500VDC Q:How many volts of external battery use ? A:48V Q:It can help Parallel ? A:No it is going to not support Q:Whats the warranty? A:1 Year Q:If it has Wifi Model ? A:Yes Q:Do it feed the flexibility to grid? A:Yes,it is on/off grid photo voltaic inverter ,Real Hybrid Inverter Q:Does the BMS specification include WIFI? A:Yes Hybrid Solar Inverter How To Turn On GRID-Tied function/Hybrid function? Press Enter Key for 3 seconds,go to 37 to environment HYD Please Note:This inverter default is off grid mode, solely you setting,then go to the Hybrid mode

•
•
•
•
•
