Description

• RF Test Board, RF Demo Kit, Frequency Test Board, NanoVNA RF Test Module Vector Network Analyzer Board Filter/Attenuator Module Feature: The board is completely incorporated with 18 practical modules Equipped with 2 pcs of UFL patch wire for convenient use The board is small and lightweight ,suitable for wearing with Each module is definitely chosen of advantageous and great reliability RF Demo Kit RF verify board demo calibration board for studying Vector Network Analyzer , Antenna Analyzer test calibration studying Specification: Item Type: RF Demo Kit The filter: Short-wave low-pass clear out LPF: 30MHz FM high-pass filter HPF: 100MHz Commonly used SAW bandpass filter BPF: 433MHz Video ceramic lure BSF: 6 RLC series and parallel circuit Includes R, L, C and combinational circuits Open /short circuit and load calibration circuit The attenuation circuit Package List: 1 x RF Demo Kit Board 2 x UFL Patch Cord Notice: 1 Dimensions are manually measured There could be a little errors 2 The photo may be slightly diverse from the particular product three Each product has passed quality inspection earlier than leaving the factory, yet we cannot make it possible for the product are not damaged throughout transportation If there is a issue together with your product, please be at liberty to let us know

•
•
•
•
•
