Description

• Model: MK32 Max Transmission Range: 15 kilometers (unobstructed, free of interference)Channels: sixteen physical channels, 16 verbal exchange channelsDatalink Compatible Flight Controllers: Pixhawk / APM founded flight controllers or any flight controllers with UART datalink outputImage Transmission Compatible Android GCS:- QGroundControl- SIYI FPVImage Transmission Compatible Windows GCS:- QGroundControlGround StationMonitor: 7-Inch High Definition and High Brightness LCD TouchscreenSystem: Android nine OS, 4G RAM & 64G ROMDimension (antenna overlapped): 308 x 148 x seventy two mmWeight: 1440 gBattery Capacity & Type: 10200 mAh 7 V 2S Li-ion, seventy five WhFast Charging Protocol: PD 30WCharging Time: three Hours (30W PD Charging)Battery Life: 10 hoursInterface & Ports:- Video Output: Standard HDMI- External Device: USB-A- MIC Input: Top Audio Port- Charging: Type-C- Firmware Upgrade: Type-C- File Transfer: Type-C / USB-A- 4G Cellular Network: SIM Card Slot- External Storage: TF Card Slot / USB-A- Communication: LAN (Ethernet)- RC Input / Output: Bottom Audio PortWaterproof Level: IP4XWorking Temperature: -10 to 50℃Air UnitSignal Output: sixteen channels of S, 5 channels of PWMInterface & Ports:- SBUS: 3-Pin- Datalink (to FC): UART 4-Pin- PWM Channel 1 to 5: 6-Pin- Video Input: Ethernet 8-Pin- Firmware Upgrade: Type-CDimensions (antenna excluded, fan included): 70 x 55 x 16 mmWeight (antenna excluded): 74 gAntenna Gain (standard omni): five dBiPower Input: eleven to sixteen V (expandable to 4S to 18S with BEC)Working Temperature: -10 to 50℃Air Unit HDMI Input Converter (Optional or Packed with HDMI Combo)Video Input Port: Mini HDMIVideo Output Port: EthernetWorking Voltage: 12 VPower Consumption: three WTF Card Recording Resolution: 1080P (1920*1080) @ 30 fps, 720p (1280 x 720) @ 30 fpsVideo Storage Bitrate: 12 MbpsFile Storage Format: FAT32Video Format: H MicroSD Cards: MicroSD Class10, Max 32GBWorking Temperature: -10 to 50℃Dimensions: 42 x 41 x eleven mmWeight: 26 g

•
•
•
•
•
