Description

• SRNE 12KW Three-Phase Hybrid Solar Inverter 48VDC To 230/400VAC Built-in Dual MPPT 260A Charger Controller PV 800VDC Max ASF48120SH3/ASP48120SH3 Note : The battery potential of the proper matching components is determined in line with the categorical usage standards of the weight and alertness scenarios, otherwise it's going to easily end in inadequate battery means or immoderate waste of strength technology For details, please discuss with the guide recommendation or consult online customer support Introduction： ASF H3 series is a brand new form of solar power storage inverter control inverter integrating solar energy storage & software charging and energy storage, AC sine wave output It adopts DSP management and features high response speed, reliability, and business common through a sophisticated management set of rules Features: • Supports lead acid battery and li-ion battery connections • With a dual activation function when the li-ion battery is dormant; either mains/photovoltaic energy supply access can trigger the activation of the li-ion battery • Support three-phase pure sine wave output (350~415V) • It has charging and discharging time sharing surroundings function • Supports part voltage adjustment within the differ of 200, 208, 220, 230, 240Vac • Supports two PV inputs, with the function of concurrently monitoring the maximum strength charging or carrying ability of two MPPT • Dual MPPT with 99% efficiency and maximum 22A recent in a single circuit, perfectly tailored to excessive strength modules • four charging modes are available: solar only, mains priority, photo voltaic priority, and combined mains/PV charging • With the time-slot charging and discharging surroundings function, you may set the term for cutting in/out of mains charging and switch the time period between battery discharging and mains bypass strength supply mode • Energy saving mode function to minimize no-load energy losses • With two output modes of software bypass and inverter output, with uninterrupted energy supply function • LCD huge screen dynamic circulate diagram design, easy to appreciate the method records and operation reputation • 360° protection with total quick circuit protection, over recent protection, over under voltage protection, overload protection, backfill protection, and many others • Support CAN, USB, and RS485 conversation Overview： Sepecification： Model ASF48120SH3 Can be set INVERTER OUTPUT Rated Output Power 12,000W Max Peak Power 24,000W Rated Output Voltage 230/400Vac(three-phase) √ Capacity of Motor Load 6HP Rated Frequency 50/60Hz √ Output Waveform pure sine wave Switching Time 10ms（typical BATTERY Battery Types Li-ion / Lead-Acid / User Defined √ Rated Battery Voltage 48Vdc Voltage Range 40～60Vdc √ Max PV Charging Current 260A √ Max Utility / Generator Charging Current 120A √ Max Hybrid Charging Current 260A √ PV INPUT No of MPPT 2 Max Input Power 9,000W/9,000W Max Input Current 22A/22A Max Open-circuit Voltage 800Vdc/800Vdc MPPT Operating Voltage Range 200～650Vdc/200～650Vdc UTILITY / GENERATOR INPUT Input Voltage Range phase voltage 170~280V, line voltage 305~485V Input Frequency Range 50/60Hz Bypass Overload Current 63A EFFICIENCY MPPT Tracking Efficiency 99% Max Battery Inverter Efficiency ≥92% European Efficiency 97% GENERAL Dimensions 620*445*130mm（2*1*0） Weight 27kg（59） Protection Degree IP20，indoor only Ambient Temp ’-10~55℃, >45℃ derated Noise <60dB Cooling Method air cooling Warranty 2 years COMMUNICATION Internal Interface RS485 / CAN / USB / Dry contact √ External Module (optional) Wi-Fi / GPRS √ CERTIFICATION Safety IEC62109-1, IEC62109-2,UL1741 EMC EN61000-6-1,EN61000-6-3,FCC15 classB RoHS Yes Item Pictures：

•
•
•
•
•
