Description

• Standard 25*25*4MM high sensitivity GPS antenna UART/TTL,232 non-obligatory interface adopt KDS zero PPM High Precision TCXO Built-in SQI Flash Built-in RTC crystal and Picofarads capacitance sizzling root Built-in LNA,Low-noise amplifier 1-10Hz Support AssistNow Online and AssistNow Offline GPS,GLONASS,GALILEO,SBAS(WAAS,EGNOS,MSAS,GAGAN) Hybrid Engine Chip:UBX-G7020-KT C/A code,1 Stream obtain frequency:L1 (1575) acquire channel:56CH S11 SWR:less than equal 1 S11 Smith:50Ohm+(-)5% S21 Log :greater than equivalent 20 S22 SWR:less than equal 1 Location Performance: Less than 2(Autonomous)(50%) Less than 2m(SBAS) rate:Less than 0/s direction:Less than 0 Degrees Timing accuracy:30ns Reference coordinate system:WGS-84 Maximum altitude:50,000 m Acceleration:Less than 4g Tracking sensitivity:-162dBm catch sensitivity:-160dBm root time:29s (in average) warm root time:28s(in average) sizzling root time:1s(in average) AGPS:3s colour:Main coloration inexperienced Material:ABS+ metal Package Contents: 1 * GPS Model 1 * Cable Only the above package content, other products are usually not incorporated Note: Light taking pictures and varied displays may cause the color of the object in the photograph a little bit different from the genuine thing The dimension allowed error is +/- 1-3cm Time of shipment: All of product we can delivery out inside 3~8 weekday, on usually we are in line with visitor orders time for packing and shipment, we need to closely verify the quality of the goods before to Ship, So take some time to handled About monitoring quantity update: If your tracking quantity is not any logistics information, as 1000's of parcels despatched to foreign countries, logistics agencies didn't replace logistics information, please contact us the first time, Please kindly don't directly open the dispute We are the 1st time for you to solve! Or you possibly can song your parcel on the following web page using your monitoring number: www/en (Copied to the browser to open)

•
•
•
•
•
