Description

• Specification: controller (Receiver) Working voltage: AC85-240V 60HZ/50HZ Working frequency: 433MHZ Power consumption in standby mode: <0 Load power: <1100W Receiving sensitivity: -108dBM Working way:wireless management Coding way: learning code Modulation: ASK Working temperature: -10*C~+70"C Size: 47*42*22 (mm) Wireless Wall Switch Working voltage: DC3 working frequency:433MHZ Power consumption in standby mode:<1uA Transmitter power: <10mW Working way: wireless management Coding way: EV1527 studying code Modulation: ASK Working temperature:-10"C~+70*C Size: 86*86* 15mm Feature: 1 switches can control varied receivers energy,avoid darkness 2 with all kinds of Lights and Ceiling Fan,CFL,Fluorescent lamp can load 300W,other can load 2500w 3 is a 86 wall panel that can be caught onto anywhere It is a studying code transmitter EV1527 IC Chip It can be learned into most of the training code receiver How to get the signal？ Step 1: Press the educational button(on the Receiver) two times Wait for three seconds; Step 2: Press one button on the handheld remote control Wait for 3 seconds Succeed How to clear the signal？ Only one step :Press the training button(on the Receiver) eight occasions Wait for 3 seconds; Please Note: Dear Customer, If in case of strength failure, and power supply is coming, swap continues to be flip on, just want long press change for 15 seconds to set

•
•
•
•
•
