Description

• Item Name: WS2812B RGB IC type: 1 IC pressure 1 led chip ( build in IC ) (The default is the chips with IC integration) R: RED Wavelength : 620-630NM Luminous intensity: 550-700MCD G: GREEN Wavelength : 515-530NM Luminous intensity: 1100-1400MCD B: BLUE Wavelength : 465-475NM Luminous intensity: 200-400MCD Description: Top SMD Type 0 Watt PIN Configuration: NO 1, Symbol: VSS Function description: Ground NO 2, Symbol: DIN Function description: Control records signal input NO 3, Symbol: VDD Function description: Power delivery LED NO 4, Symbol: DOUT Function description: Control data signal output Absolute Maximum Ratings: ( Ta=25 ℃,VSS=0V ) Power supply voltage Symbol: V(DD) Range: +3 - +5 Input voltage Symbol: V(I) Range: -0 - VDD+0 Working temperature Symbol: Topt Range:-25 - +80 ℃ Storage temperature Symbol: Tstg Range: -40 - +105 ℃ Package Include: 10~1000pcs WS2812B LEDs

•
•
•
•
•
