说明

• Quantity : 1 pcs Size : 25 Model Number : F405HD For Vehicle Type : Airplanes RC Parts & Accs : Connectors/Wiring Material : Composite Material Brand Name : RCMOY Origin : Mainland China Recommend Age : 14+y Use : Vehicles & Remote Control Toys The Super F405HD ELRS AIO flight controller comes with included UART 2 ExpressLRS receiver and 20A Blheli_s ESC(Bluejay firmware pre-installed) which could support 2-4s battery Bigger Mosfet could support excessive to 20A currents and reserved 6 pin socket for DJI HD package plug and play It's solution of construct 2-4S HD electronic FPV whoop gentle controller MCU: STM32F405RGT6 (168MHZ, 1Mbyte FLASH) GYRO Sensor: ICM42688 (SPI connection) Mount gap size: 25mm*25mm Power supply: 2~4S battery enter (DC 8) Built-in 20A(each) Blheli_S 4in1 ESC Built-in Serial ExpressLRS 2 (Default linked to UART2) Built-in BMP280 Barometer Built-in 8MBp blackbox Built-in voltage meter sensor , voltage meter scale 110 Built-in current meter sensor , recent meter scale 470 Flight controller firmware target: BETAFLIGHTF4 Onboard 4in1 ESC MCU upgraded to EFM8BB21 Power supply: 2-4S LiPo/LiPo HV (7v/17v) Currents: 20A continual top 25A (5 seconds) Support BLHeliSuite programmable Factory firmware: Bluejay 0 Firmware target: F_H_40_48_v0 Default protocol: DSHOT150/DSHOT300/DSHOT600 Onboard UART ExpressLRS 2 Receiver Packet Rate option: 25Hz/50Hz/150Hz/250Hz/500Hz RF Frequency: 2 plug: IPEX Telemetry output Power: <12dBm Receiver protocol: CRSF Default firmware version: ExpressLRS V3 Onboard voltage and Amperage meters settings Voltage meter scale atmosphere one hundred ten Amperage meter scale atmosphere 470 Binding procedure: Supply power to the flight controller through plug USB, wait until the crimson LED on the FC is off, instantly turn off the power, after which repeat back the above steps When the FC is powered on for the 0.33 time, the red LED gentle will start to double-flash, this means that the Receiver enters the binding mode Please make certain your ExpressLRS tx module firmware is v3 And go to ExpressLRS from ''TOOLS'' menu of your radio transmitter Then hit [Bind] to binding with the onboard ExpressLRS receiver The red LED should blinking slowly first then turn to solid, which means binding changed into successfully If the pink led preserve tri-flash after binding ,please exchange Model Match tab price from ''off'' to ''on'' or from ''on'' to ''off'' Receiver LED reputation meanings: Red LED stable means bind profitable or RC link established; Red LED double-flash means get into bind mode; Red LED flash slowly potential no RC signal enter from TX module; Red LED continual flash immediate capability ExpressLRS wifi enabled; Red LED tri-flash potential mannequin mismatch need to substitute mannequin tournament from ''off'' to ''on'' UART description: ELRS receiver turned into related to UART2 default out of manufacturing unit Usually UART1 became used for MSP OSD with HD VTX UART6 would be used for GPS or different serial equipment IRX6 is an inverted serial RX6 for SBUS enter IRX6 and TX6/RX6 could not be used on the similar time NOTES: If improve firmware to betaflight 4 , should upload tradition Defines ''GYRO_SPI_ICM42688P ACC_SPI_ICM42688P'' from build configuration of betaflight configurator otherwise gyro will not working If you prefer to enable Barometer , please connect to betaflight configurator and go to CLI command ,then sort the ensuing command: resource I2C_SCL 2 B10 useful resource I2C_SDA 2 B11 set baro_bustype = I2C set baro_i2c_device = 2 save

•
•
•
•
•
