• STEP 1: Choose an accurate management Mode AA- AC Control AC DA- DC Control AC DD- DC Control DC VA-Control and Adjust STEP 2: Choose a correct variety Current of Equipment/Ratio = Current of SSR PS: The Ratio rely on the type of your loading package Resistive load :70%, Inductive load:20%,Capacitive load：10% STEP 3: Choose an acceptable heat sink During the useage of SSR, it's going to give out a lot of heat, so in order to make bigger the life of your SSR, please install a heat sink , also if the current is over 60A,the cooling fan also required PS: Our Heat Sink consist of 2 screws (for install heat sink) NOTICE: The inside of the solid-state relay is a semiconductor A semiconductor swap is a non-physical contact swap if use a multimeter diode or resistor to test ,it constantly demonstrate a high-impedance state, (multimeter mild red) According to the standard detection tips of strong state relays: a load is required to test the switching state Using an incandescent lamp as a dummy load is an obvious option to examine continuity

•
•
•
•
•
