• Feature: 1 DP sequence high?voltage differential probes, specially designed for the size of high?voltage differential indicators 2 The energy delivery adopts USB DC 5V output and has a USB interface, which is easy to apply and bring 3 High?voltage differential probes sample high?impedance isolation between enter and output to guard person security 4 Convert the input high voltage signal to low voltage signal for oscilloscope commentary and analysis five The attenuation fee is 10X, which are used in any brand of oscilloscope, meet the needs of floating size Specification: Condition: one hundred pc Brand New Item Type: Oscilloscope Probe Material: ABS Model DP10007 Bandwidth 100MHZ Rise Time 3 Attenuation 10X 100X Accuracy ±1% Maximum Input Differential Voltage (DC+AC) 70V (10X) 700V (100X) Maximum Common Mode Input Voltage CAT II 600V CAT I 1000V Reference Noise ≤15m Vrms(10X) ≤60mVrms(100X) Common Mode Override Ratio ≤-80dB at 50HZ ≤-50dB at 1MHZ ≤-60dB at 20KHZ ≤-40dB at 10MHZ Input Resistance 8MΩ/1 (Differential) 4MΩ/2 (Single End to Ground) Output Voltage ≤7V Power 1 Power Supply DC 5V, USB Power Supply Overload Indication Button Light Flashes Size Approx 14 / five Input Line Length Approx 45cm / 17 Output Line Length Approx 90cm / 35 Temperature 0℃-40℃ Humidity 10%-85% Operation Instruction 1 Supply: USB DC 5V Output, extra transportable whereas oscilloscope have USB interface 2 the Product: To keep away from electric shock, the grounding conductor should be connected to earth floor Before making connections to the input or output terminals of the product, make sure that the product is properly grounded 3 Connection: Connect probe energy enter port to USB cable power output port, then connect the probe BNC port to oscilloscope or other instruments BNC port, set proper attenuation rate, and fasten the probe with the measuring object 4: You should estimate the tested voltage amplitude earlier than testing, do not use if exceeds the voltage fluctuate 5 Disconnection: First disconnect the inputs from the tested points,and then unplug the probe output and tool enter Package List: 1 x Probe 2 x Clip 2 x Probe Hook 2 x Test Bar 1 x USB Cable 1 x Plastic Box 1 x Manual Note: 1 Please allow 0?1 inch error due to guide size Thanks to your figuring out 2 Monitors should not calibrated same, merchandise colour displayed in pictures could also be showing slightly different from the real object Please take the real one as common

•
•
•
•
•
