Descriptions

• Note:The relay controller is wifi+rf,the wall swap is rf solely replace itself can't management lighting fixtures on off must work with wifi+rf receiver together+ RF controller (Receiver)Input energy : AC 85-240V RF Frequency : 433MHz WIFI Frequency : 2 WiFi Standard : IEEE 802 b/g/n Size : 41*41*20 (mm) Max Current : 16A Shell : Yes Port : L/N Certification : CCC,CE,RoHS Feature : Has WiFi Function Feature2 : Can Work with Tuya,Smart Home Feature3 : Time Function Feature4 : Voice Control through Google Home,Amazon AlexWireless Wall Switchworking frequency:433MHZ Power consumption in standby mode:<1uA Transmitter power: <10mW Working way: wireless control Coding way: EV1527 studying code Modulation: ASK Working temperature:-10"C~+70*C Size: 86*86* 15mmHow to get the signal?Step 1: Press the educational button(on the Receiver) twice. Wait for three seconds; Step 2: Press one button on the remote control. Wait for 3 seconds. Succeed to clear the signal?Only one step :Press the academic button(on the Receiver) eight times. Wait for three seconds;

•
•
•
•
•
