• Ball Holder LM Rolling Guide Radial HSR Structure and Features:The metal ball rolls along 4 rows of precision ground rolling surfaces at the LM song and LM slider; By assembling the top disguise plate at the LM slider, the steel ball column is cyclically moved.The LM slider makes use of a conserving plate to carry the metallic ball, so even though the LM slider is removed from the LM track, the steel ball won't fall off (except for HSR8, 10, and 12 types).In order to make sure that all 4 instructions of motion (radial, anti radial, and lateral) at the LM slider have the same rated load, each metallic ball column is designed to have a touch attitude of 45 degrees? Configuration, so it can be utilized in any posture. And because of the ability to use equal preload, it can preserve a low friction coefficient whereas modifying tension in all 4 directions. Meanwhile, due to the low cross-sectional peak and the high tension design of the LM slider, stable high-precision linear movement can be achieved.【Four directional equal load】In order to ensure that all 4 directions of action (radial, anti radial, and lateral) at the LM slider have an analogous rated load, every single steel ball column is designed to be configured at a touch perspective of forty five °, so it may be utilized in any posture and has quite a lot of applications.【High stress type】Due to the configuration of steel balls being organized in four rows with nice balance, enough preloading can be utilized and the stress in all four instructions could be smoothly improved.【Automatic heart adjustment ability】Due to THK's unique entrance combination of circular grooves (DF combination), which has automatic centering capability, it will soak up set up errors even when preloaded, resulting in high-precision, comfortable and stable linear motion.【Excellent durability】Even beneath the motion of preloading or bias load, the differential sliding of the steel ball is minimized, achieving long-term maintenance of excessive wear resistance and accuracy.【Stainless metal sort is also available】LM sliders, LM rails, and metal balls is also manufactured from stainless steel.

•
•
•
•
•
