Description

• Specification: Description: BLDC broad voltage 7-24V high-power small-volume potentiometer pace control Brushless and Hallless controller, single-button version helps single-button loose switching acceleration and deceleration with power-off memory function potentiometer pace management edition helps PLC 0-5V simulation Signal speed Instructions to be used of potentiometer models: The common energy distribution positioner straight regulates the rate with out exterior management alerts It will increase clockwise and decreases counterclockwise It is also appropriate for exterior PLC 0-5 analog quantity control Unplug the potentiometer cable, the external 0-5 analog number management sign and floor wire are respectively connected to the enter signal terminal of the brushless driver board, as long as two wires are OK Interface Description: 1 U V W section line output is connected to the motor 2 VCC GND leading strength supply (external DC power supply) Product parameters: 1 name: Potentiometer three-phase DC brushless and Hallless pressure 2: X30 V2(potentiometer) 3 voltage: 7-24V four current: rated 15A plus fan cooling 20A five speed: 224000 RPM (2 pole motor), 74000 RPM (6 pole motor), 40000 RPM (12 pole motor), 35000 RPM (14 pole motor) 6 size: size 45MM*width 26MM*height 12MM (excluding wires and sticking out capacitors) Features: ESC is specifically evolved and designed for commercial management electric instruments equivalent to air pumps, water pumps, oil pumps, fans, and so on that use DC three-phase brushless motors The default is medium timing and long-time high-current operation Jianyijia fan cooling does have overheat protection The poor exterior warmth dissipation circumstances of the ESC will automatically cut the power when the temperature exceeds one hundred degrees, and the temperature will return to common when it drops to one hundred levels Precautions: 1 There is not any fuse in the strength delivery circuit on the motherboard Jianyi has added it himself Reverse connection of the advantageous and detrimental poles of the ability delivery will cause permanent damage to a few of the chips at the board (even if it would not paintings for 1 second) 2 There is motor blocking off protection during traditional operation Because the ability and recent of the module are large, please do not artificially short-circuit when the module isn't operating usually Once the short-circuit may perhaps burn the road and the tube may well burst, please use the small for the first wiring test Current low voltage test, after ok, then go high recent and high voltage to paintings three Do not join the motor that's needless to say inconsistent with the drive module voltage, current, or power, to circumvent inexplicable "nonsensical" injury Package List: Driver Board x 1pcs

•
•
•
