• Happymodel Elrs F4 2g4 Aio 5in1 Flight Controller SPI 2 ExpressLRS Receiver 5 VTX The first AIO 5in1 F4 flight controller with integrated SPI 2 ExpressLRS receiver has been released The flight controller integrates SPI controlled 2 ExpressLRS receiver, Dshot protocol 4-in-1 ESC, 5 40ch video transmitter and Betaflight OSD Ultra-small length and ultra-stable handheld remote control range can upgrade the range of the unique SPI receiver And since the 2 ExpressLRS receiver is equipped with the SX1280 radio frequency chip with high sensitivity, high packet price and coffee latency, this flight controller is the one that all Race/Freestyle pilots vital It is acceptable to be used in Tiny whoop Race or Toothpick Freestyle, and might also be utilized in 1S ultra-lightweight Nano Long Range platform Specifications: MCU: STM32F411CEU6 (100MHZ, 512K FLASH); Sensor: MPU-6000 (SPI connection); Original Whoop Size Compatible; Power Supply: 1S Battery input (DC 2); Flight Controller: Built-in 5A (each) Blheli_S 4in1 ESC Dshot600 Ready; Built-in Betaflight OSD (SPI Control); Built-in five VTX; Built-in SPI ExpressLRS 2 Receiver; Built-in 5V 1A BEC; Flight controller firmware target: CRAZYBEEF4SX1280； Bind procedure: 1 Power the flight controller through connecting USB Please be sure that the port driving force of the flight controller is properly put in on the computer, then open Betaflight Configurator(Latest version) to connect, input to the "receiver" interface, and then click on "Bind Receiver", the red LED on the bottom of the flight controller will flash quickly, because of this the SPI ELRS receiver enters the bind mode There is otherwise to make the receiver enter the bind mode: after connecting to the Betaflight configurator, stream to the CLI interface and input "bind_rx" in the command line 2 After wisely connecting the ES24TX or ES24TX Lite/Slim module or DIY 2 ELRS TX module for your Opentx radio transmitter, replica the newest edition of ELRS file to the SD card in the remote controller The listing is "SD Card/Scripts/tools", Then run ELRS and improve the desired TX frimware via Wifi, after which click "bind" to hyperlink with the SPI ExpressLRS receiver Note: You deserve to alter the Packet Rate to 500Hz from the ELRS interface of your radio controller earlier than binding three After the binding is successful, the Red LED on the backside of the flight controller will getting to be solid, and the telemetry could be acquired at the similar time 4 The which means of the LED fame of the SPI receiver: the LED is getting to be solid, indicating that the bind is profitable or the relationship and communique is normal, the LED flashing quickly signifies that the receiver is in binding mode, and the LED flashing slowly indicates that the there is not any sign received from the radio controller Some helpful firmware and instruments download

•
•
•
•
•
